| ₹ 502.32 includes GST and import duties. | |
| B2B customers can avail ₹ 76.6 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
The INA226AIDGST is a Current Shunt and Power Monitor with an I²C�- or SMBUS-compatible interface. The device monitors both a shunt voltage drop and bus supply voltage. Programmable calibration value, conversion times and averaging, combined with an internal multiplier, enable direct readouts of current in amperes and power in watts. The INA226AIDGST senses current on common-mode bus voltages that can vary from 0 to 36V, independent of the supply voltage. The device operates from a single 2.7 to 5.5V supply, drawing a typical of 330µA of supply current. The device is specified over the operating temperature range between -40°C and 125°C and features up to 16 programmable addresses on the I²C-compatible interface.
- Senses bus voltage from 0 to 36V
- High-side or low-side sensing
- Reports current, voltage and power
- 0.1% Gain error (maximum) and 10µV offset (maximum) high accuracy
- Configurable averaging options
- 16 Programmable addresses
- Green product and no Sb/Br
Communications & Networking, Computers & Computer Peripherals, Power Management, Maintenance & Repair, Test & Measurement
Warnings Device has limited built-in ESD protection. The leads should be shorted together or the device placed in conductive foam during storage or handling to prevent electrostatic damage to the MOS gates.Other details
| Brand | TEXAS INSTRUMENTS |
| Part Number | INA226AIDGST |
| Quantity | Each (Supplied on Cut Tape) |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 492.27 |
| 3-5 | ₹ 487.25 |
| 5-10 | ₹ 477.2 |
| 10+ | ₹ 467.16 |
Bulk discount will be automatically applied during checkout based on quantity.
