Description
The CA3KN40BD from Schneider Electric is a four pole TeSys K IEC control relay with normally open (NO) contacts.
- Screw clamp connection
- Coil voltage of 24VDC
- Approved by IEC 60947, NF C 63-140, VDE 0660, BS 5424 UL, CE and CSA standards
- Ambient operating air temperature range from -25�C to 50�C
- Rated operational voltage of 690V
- Rated operational current of 10A
Applications
Automation & Process Control, Industrial
Product details
| Relay Mounting | DIN Rail |
| Coil Voltage VDC Nom | 24V |
| Switching Current AC1 | - |
| Load Current Resistive | 10A |
| Product Range | TeSys CAK Series |
| Switching Current AC3 | - |
| Coil Voltage VAC Nom | - |
| Operating Voltage | 600VAC |
| No. of Poles | 4 Pole |
| Load Current Inductive | 10A |
| Contact Configuration | 4NO |
| Switching Power AC3 | - |
| Switching Power AC1 | - |
Other details
| Brand | SCHNEIDER ELECTRIC / TELEMECANIQUE |
| Part Number | CA3KN40BD |
| Quantity | Each |
| Technical Data Sheet EN |  |
