Description
The 5-146130-2 is a 6-position 2-row square vertical unshrouded Breakaway Surface-mount Header with 0.00076mm gold-plated phosphor bronze pin contact and black 94V-0 rated thermoplastic housing. This plug supports through-hole PCB mounting style. It is applicable to?printed circuit board.
- 0.64mm Post size
- High temperature housing is capable of withstanding IR or vapour phase reflow
Applications
Industrial
Product details
| No. of Contacts | 6Contacts |
| Contact Plating | Gold Plated Contacts |
| Gender | Header |
| Product Range | AMPMODU MOD II Series |
| Contact Material | Phosphor Bronze |
| Contact Termination Type | Surface Mount |
| Pitch Spacing | 2.54mm |
| No. of Rows | 2Rows |
Other details
| Brand | TE CONNECTIVITY |
| Part Number | 5-146130-2 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Drawing EN | |
| 3D Product Image EN | |
