Description
Elo Touch 5503L Overview
- 1Description
- 2Elo Edge Connect
- 3Controlling the Display Remotely
- 4Elo Advance Unit Replacement
- 5Additional Features
Add interactivity to virtually any environment with the 5503L 55" Class Full HD TouchPro PCAP Interactive Commercial Display from Elo Touch. The 5503L is a 382 nits bright, 55" diagonal, 1920 x 1080 display with 24/7 playback, built to withstand the rigors of continuous commercial use. It is ideal for demanding environments like retail, restaurant, corporate, and healthcare.
Connect to a wide array of computers and media players with HDMI, DisplayPort, and USB-C inputs. Elo's TouchPro PCAP touch technology enables up to 40 touch points and delivers fast and sensitive responses. Elo's TouchPro PCAP also offers anti-friction glass to minimize heat as fingertips drag across the screen and touch thru capability, allowing the interactive display to be mounted behind a mirror, in a counter or in a fully encased kiosk for added durability or aesthetics. Additionally, with Elo's computer modules (sold separately), you can easily turn the display into a powerful, all-in-one, life-size tablet.
- Built-in 10W stereo speakers
- 3.5mm headphone out
- HDMI CEC functionality
- Real Time Clock functionality
- Wake on touch
- Ambient light sensor with intelligent brightness control and color sensor functionality
- Energy saving mode meeting Energy Star 8.0 requirements
In the Box
- Elo Touch 5503L 55" Class Full HD TouchPro PCAP Interactive Commercial Display
- HDMI Cable
- USB-A to USB-C Cable
- Power Cable
- Serial 3.5mm Male to Serial DB9 Female Cable (MDC Cable)
- Limited 3-Year Manufacturer Warranty (Includes Advance Unit Replacement)
- Description
- Elo Edge Connect
- Controlling the Display Remotely
- Elo Advance Unit Replacement
- Additional Features
Elo Touch 5503L Specs
| Panel Type | TFT LCD |
| Aspect Ratio | 16:9 |
| Display Orientation | Face-Up, Landscape, Portrait |
| Resolution | 1920 x 1080 |
| Maximum Brightness | 382 nits / cd/m2 (Sustained) |
| Contrast Ratio | 4000:1 |
| Response Time | 8 ms |
| Refresh Rate | 60 Hz |
| Bit Depth / Color Support | 8-Bit+FRC (1.07 Billion Colors) |
| Horizontal Frequency | 30 to 69 kHz (Digital) |
| Vertical Frequency | 24 to 64 Hz (Digital) |
| Pixels Per Inch (ppi) | 40 ppi |
| Touchscreen Technology | Projected Capacitive |
| Multi-Touch Points | 40 |
| TV Tuner | No |
| USB I/O | 1 x USB-C Unspecified Version (Video/Touchscreen Control) 4 x Micro-USB 2.0 |
| Ethernet I/O | 1 x RJ45 (Unspecified Ethernet) |
| Ambient Light Sensor | Yes |
| Built-In Speakers | Yes, 2 x 10 W |
| Speaker Configuration | 2-Channel |
| Mobile App Compatible | No *As of May, 2023: Check with manufacturer for the most up-to-date compatibility |
| Digital Media Slot | None |
| Built-In Mic | No |
| Operating Temperature | 32 to 72°F / 0 to 40°C |
| Storage Temperature | -4 to 140°F / -20 to 60°C |
| Operating Humidity | 20 to 80% (Non-Condensing) |
| Storage Humidity | 10 to 95% (Non-Condensing) |
| Power Consumption | Typical: 81.0 W Quick Start Mode: 1.8 W Standby: 0.3 W |
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
| Power Adapter Type | Internal |
| Certifications | UL 62368-1, FCC , cUL , IC , CB, IEC-EN60950-1/EN62368-1, CE, VCCI, RCM, CCC, RoHS, EAC, NOM, ENERGY STAR 8.0 *as per Manufacturer |
| Lighting Lifespan | 50000 Hours |
| IK Rating | IK07 |
| Duty Cycle | 24 Hours / 7 Days |
| Dimensions | 50.1 x 29.2 x 3.1" / 1271.8 x 742.6 x 80 mm |
| Weight | 77.69 lb / 35.24 kg |
