LG UH5J Series 65" 4K Smart LED Commercial Display

Durable Display

When the display is used in public spaces, the location can't always be strictly climate-controlled. This is why LG constructed the UH5J display to earn an IP5X rating and gave it a conformal coating on the power board. This helps to protect the circuit boards from both dust and moisture from high-humidity environments.

Control and Management

The UH5J series commercial display supports a wide range of control and management options to make it easier for employees and technicians to work with and support installations.

• Promota Mobile App: For iOS and Android, this app lets you create custom templates from recommendations to promote content on the display.
• AV Control System: Certified Crestron Connected, this display seamlessly integrated with an existing Crestron network-based control system.
• Embedded CMS: This feature includes both local content scheduling and a group manager.

Custom Logo

Add a professional touch to the display with the ability to show a custom logo on boot, and a "no signal" image when there are connection issues.

Tile Mode

The UH5J can be used individually or as part of a much larger installation. Using Tile Mode, the UH5J display can integrate into a larger video wall of up to 15 x 15 matrix.

LG Software Compatibility

This display is compatible with the following LG applications:

• SuperSign CMS
• SuperSign Control/Control+
• SuperSign WB
• SuperSign Media Editor
• Promota (not available in EU/CIS)
• Mobile CMS
• LG ConnectedCare

Additional Features

• Portrait or landscape mounting
• Wi-Fi connectivity
• 16GB of internal storage
• Multi-screen PIP/PBP
• Screen Share
• Video Tag
• Play via URL
• Screen & External Input Rotation
• Gapless Playback
• Setting data cloning
• SNMP
• ISM method
• Auto set ID
• Status mailing
• PM Mode & Wake on LAN
• SI server setting
• webRTC
• Pro:Idiom

LG UH5J Specs

Display Size	65"
Native Resolution	3840 x 2160
Maximum Brightness	500 nits / cd/m2
Inputs	3x HDMI 1x DisplayPort 1x DVI-D 1x 1/8" / 3.5 mm (Analog Audio)
Outputs	1x HDMI 1x 1/8" / 3.5 mm (Analog Audio)
Wireless	Wi-Fi
USB I/O	2x USB-A 2.0 (Audio/Video/Charging)
Ethernet I/O	1x RJ45 (Unspecified Ethernet)
Other I/O	1x 1/8" / 3.5 mm Serial (RS-232C) Control Input 1x 1/8" / 3.5 mm Serial (RS-232C) Control Output 1x 1/8" / 3.5 mm IR / Ambient Sensor Input
Built-In Speakers	Yes
Media Card Reader	No

Display Size	65"
Panel Type	IPS-Type LCD
Aspect Ratio	16:9
Display Orientation	Landscape, Portrait
Native Resolution	3840 x 2160
Maximum Brightness	500 nits / cd/m2
Lighting System	Edge-Lit LED
Contrast Ratio	1100:1
Dynamic Contrast Ratio	1,000,000:1
Response Time	8 ms (GtG)
Refresh Rate	60 Hz
Color Support	1.07 Billion Colors (10-Bit)
Color Gamut	95% Rec. 709
Viewing Angle (H x V)	178 x 178°
Pixels Per Inch (ppi)	68 ppi
Finish	Anti-Glare / Matte

Haze Level

28%

TV Tuner

No

Inputs	3x HDMI 1x DisplayPort 1x DVI-D 1x 1/8" / 3.5 mm (Analog Audio)
Outputs	1x HDMI 1x 1/8" / 3.5 mm (Analog Audio)
HDCP Support	Yes, Version 2.2
Wireless	Wi-Fi
USB I/O	2x USB-A 2.0 (Audio/Video/Charging)
Ethernet I/O	1x RJ45 (Unspecified Ethernet)
Other I/O	1x 1/8" / 3.5 mm Serial (RS-232C) Control Input 1x 1/8" / 3.5 mm Serial (RS-232C) Control Output 1x 1/8" / 3.5 mm IR / Ambient Sensor Input
Ambient Light Sensor	Yes
Multi-Input Support (PIP/PBP)	Picture-in-Picture (PIP), Picture-by-Picture (PBP)

Built-In Speakers

Yes

Smart TV	webOS 6.0
Storage	16 GB
OS Compatibility	Android Only
Mobile App Compatible	Yes: Android Only
Media Card Reader	No
Built-In Mic	No

Supported Languages

Arabic Brazilian Portuguese Czech Danish Dutch English Finnish French German Greek Italian Japanese Korean Norwegian Portuguese Russian Simplified Chinese Spanish Swedish Traditional Chinese Turkish

Power Consumption	Typical: 130.0 W Maximum: 190.0 W Standby: 0.5 W
Input Power	100 to 240 VAC, 50 / 60 Hz

Operating Conditions	32 to 104°F / 0 to 40°C at 10 to 80% Humidity
Certifications	ENERGY STAR, FCC Class A, CE, CB, NRTL, ErP
Adjustments	Tilt: 30°
Mounting-Hole Pattern	300 x 300 mm
Lighting Lifespan	50000 Hours
Environmental Resistance	Dust-Resistant (IP5X)
Bezel Thickness	9.9 mm (Right/Top/Left) 14.4 mm (Bottom)
Duty Cycle	24 Hours / 7 Days
Dimensions	57.2 x 33.2 x 1.6" / 1453.3 x 844 x 39.9 mm (without Handle) 57.2 x 35.2 x 11.4" / 1453.3 x 893.1 x 290 mm (with Stand)
Weight	62.2 lb / 28.2 kg (without Stand) 63.5 lb / 28.8 kg (with Stand)

Package Weight	76 lb
Box Dimensions (LxWxH)	65 x 41 x 9"
