Optoma Technology Creative Touch 5653RK 65" UHD 4K Touchscreen Commercial Monitor

Extensive Connectivity

The 5653RK features a wide variety of connections to support an array of devices. DisplayPort, USB-C, and four HDMI 2.0 inputs support up to 4K60 video. Plenty of USB ports are available to support touch control from external devices, add peripherals like cameras, or play media files directly from USB flash drives. You can easily access the front-facing ports for HDMI and USB connectivity, including a full-function USB-C with up to 100W power delivery (65W if OPS device is installed).

When the display is connected to a network via Ethernet or Wi-Fi (optional adapter sold separately), Optoma's CreativeCast Pro allows up to four users to share content at the same time from their Windows, iOS, macOS, Chrome, or Android device. Equipped with an OPS slot, and easy to download OTA updates, the touchscreen display is future-proofed should your requirements change in the ever-changing world of technology.

Optoma Whiteboard and Annotation

Creative sharing is easy with built-in annotation tools to help facilitate collaboration in the classroom. Designed for hybrid working, the Optoma White Board provides smart collaboration and connectivity features for any classroom. The 5653RK features up to 40 points of touch with pen and finger recognition for a seamless and user-friendly writing experience. Additionally, with this display, two teams or individuals can work together from two separate locations in real-time.

Display Share

Wirelessly display and share content on the big screen using the Display Share app or desktop software. Easily mirror your Android, iOS, Windows, macOS, or Chrome device at the touch of a button, or wirelessly cast images and documents stored on your mobile device. The app also acts as a wireless mouse and keyboard allowing you to control your display.

Infinity Canvas

Never run out of space during a lesson. With the ability to draw anywhere, insert images and shapes, all of which can be saved, printed, or shared with student devices, the infinity canvas will not limit your creativity, and expands your workspace.

OMS Integrated Display Management

Teachers can have peace of mind knowing their IT managers can support them remotely using Optoma's Management Suite (OMS) solution. IT managers can monitor and diagnose issues with any AV display, so teachers aren't left in the dark. Teachers can also set alerts and broadcast emergency announcements.

Interactivity for Education

• Included quick-draw pen and holder instantly activates the whiteboard application
• Floating toolbar can be placed anywhere on the infinity canvas
• The toolbar allows you to select tools, such as an eraser, ruler, and highlighter, change colors, or import images
• Designed to support distance learning
• Connect to webcams and other visualizers
• Sync with cloud accounts, including Google Classroom, to plan lessons from anywhere

Additional Features

• Free 1-year mozaBook subscription with product registration
• Vizetto Reactiv SUITE software, 1-year license included
• Integrated Google Play Store
• Android 13 OS for improved multitasking and security
• Optional sensor box: NFC reader and air quality sensors
• Integrated 8-microphone array
• Embedded dual 18W speakers and 8W subwoofers

Optoma Technology CREATIVE TOUCH 5 Specs

Display Size	65"
Native Resolution	3840 x 2160
Maximum Brightness	400 nits / cd/m2
Touchscreen Technology	Infrared (IR)
Inputs	4x HDMI 2.0 1x DisplayPort 1x 1/8" / 3.5 mm
Outputs	1x HDMI 2.0 1x TOSLINK Optical
Wireless	Wi-Fi 6 (802.11ax) / Bluetooth
USB I/O	1x USB-A (Unspecified Version) (Service) 4x USB-A 3.0 / 3.1/3.2 Gen 1 (Audio/Charging/Photo/Video/Control/Touchscreen Control) 2x USB-C (Unspecified Version) (Audio/Charging/Photo/Video/Control/Touchscreen Control)
Ethernet I/O	2x RJ45 (Unspecified Ethernet)
Other I/O	1x DE-9/DB-9 Serial (RS-232C) Control Input
Built-In Speakers	Yes, 4
Media Card Reader	No

Display Size	65"
Panel Type	LCD
Aspect Ratio	16:9
Display Orientation	Landscape
Native Resolution	3840 x 2160
Maximum Brightness	400 nits / cd/m2
Lighting System	Direct LED
Contrast Ratio	5000:1
Dynamic Contrast Ratio	6000:1
Response Time	< 8 ms
Refresh Rate	60 Hz
Color Support	1.07 Billion Colors
Viewing Angle (H x V)	178 x 178°
Screen Area	56.2 x 31.7" / 1428 x 804 mm
Pixels Per Inch (ppi)	68 ppi
Finish	Anti-Glare / Matte

Touchscreen Technology	Infrared (IR)
Multi-Touch Points	50
Hardness Rating	9H
Haze Level	3%

TV Tuner

No

Inputs	4x HDMI 2.0 1x DisplayPort 1x 1/8" / 3.5 mm
Outputs	1x HDMI 2.0 1x TOSLINK Optical
HDCP Support	Yes
Wireless	Wi-Fi 6 (802.11ax) / Bluetooth
Connection Protocols	AirPlay, Chromecast built-in
NFC	No
USB I/O	1x USB-A (Unspecified Version) (Service) 4x USB-A 3.0 / 3.1/3.2 Gen 1 (Audio/Charging/Photo/Video/Control/Touchscreen Control) 2x USB-C (Unspecified Version) (Audio/Charging/Photo/Video/Control/Touchscreen Control)
Ethernet I/O	2x RJ45 (Unspecified Ethernet)
Other I/O	1x DE-9/DB-9 Serial (RS-232C) Control Input
Number of OPS/Expansion Slots	1
Ambient Light Sensor	Yes
Multi-Input Support (PIP/PBP)	Picture-in-Picture (PIP)

Built-In Speakers	Yes, 4
Speaker Configuration	2.1-Channel

Smart TV	Android 13
CPU	8-Core:  A76 (4 Core) A55 (4 Core)
Storage	65 GB
RAM	8 GB
Media Card Reader	No
Built-In Mic	Yes

Supported Video File Types	3GP, AVI, FLV, H.263, H.264/AVC, MJPEG, MKV, MOV, MP4, MPEG, MPEG2, MPEG4, MPG, TS, VOB, VP8, VP9, WEBM
Supported Audio File Types	AAC, APE, FLAC, M4A, MP1, MP2, MP3, OGG, WAV
Supported Photo File Types	BMP, GIF, JPEG, JPG, PNG
Supported Languages	Arabic Czech Danish Dutch English French German Italian Polish Portuguese Romanian Russian Simplified Chinese Spanish Swedish Traditional Chinese Turkish

Power Consumption	Maximum: 380.0 W Typical: 200.0 W Eco Mode: 116.0 W Standby: 0.5 W
Input Power	100 to 240 VAC, 50 / 60 Hz
Power Adapter Type	Internal

Operating Conditions	32 Up to 104°F / 0 to 40°C
Certifications	FCC, WEEE, ENERGY STAR
Mounting-Hole Pattern	600 x 400 mm
Lighting Lifespan	50000 Hours
