Provided by third party: Supermicro provides the outstanding product line, their proven high level of quality and performance has made SuperServers the platform of choice for enterprise, cloud, data center, hyperscale, embedded, and business-critical, front-end server applications.
- Key Features
-
- Improved memory slots
- 1x PCI-E 3.0 x16 (LP) slot
- Dual-port GbE LAN
- Hot-swap SATA3 drive bays
- Redundant power supplies
- 2x SATA DOM
UPC: 672042193165
Supermicro 2028TR-HTR specs
| General |
| Type | Cluster (4 nodes) |
| Product Form Factor | Rack-mountable - 2U |
| Server Scalability | 2-way |
| Cluster Configuration | 4 - computing node |
| Color | Black |
| Processor / Chipset |
| CPU | No CPU |
| Max CPU Qty | 2 |
| CPU Upgradability | Upgradable |
| CPU Socket | LGA2011-v3 Socket |
| Chipset Type | Intel C612 |
| RAM |
| Installed Size | 0 MB / 1 TB (max) |
| Technology | DDR4 SDRAM - ECC |
| Form Factor | DIMM 288-pin |
| Features | Registered, Load-Reduced DIMM (LRDIMM), 3DS Load-Reduced DIMM (LRDIMM) |
| RAM Supported | 1 TB 3DS Load-Reduced - ECC
256 GB registered - ECC |
| Storage Controller |
| Type | 1 x RAID |
| Controller Interface Type | SATA 6Gb/s |
| Channel Qty | 8 |
| RAID Level | RAID 0, RAID 1, RAID 5, RAID 10 |
| Networking |
| Ethernet Ports | 2 x Gigabit Ethernet |
| Ethernet Controller | Intel I350 |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Remote Management Protocol | IPMI 2.0 |
| Remote Management Controller | Aspeed AST2400 |
| Features | KVM over IP support |
| Cluster |
| Shared Storage Power Supply | 2 redundant hot plug power supplies |
| Power Supply Capacity | 2x1600 Watt |
| Expansion / Connectivity |
| Bays | 6 (total) / 6 (free) x hot-swap 2.5" |
| Slots | 2 (total) / 2 (free) x CPU
8 (total) / 8 (free) x DIMM 288-pin
1 (total) / 1 (free) x PCIe 3.0 x16 - low-profile |
| Interfaces | 2 x LAN (Gigabit Ethernet)
2 x USB 3.0
1 x VGA
1 x management - RJ-45
1 x serial |
| Miscellaneous |
| Included Accessories | 4 x riser card, 8 x CPU Heatsink |
| Compliant Standards | Plug and Play, ACPI 2.0, APM 1.2, RoHS |
| Power |
| 80 PLUS Certification | 80 PLUS Titanium |
| Manufacturer Warranty |
| Service & Support | Limited warranty - parts - 1 year
Limited warranty - labor - 3 years |
| Environmental Parameters |
| Min Operating Temperature | 50 °F |
| Max Operating Temperature | 95 °F |
| Humidity Range Operating | 8 - 90% (non-condensing) |
