Description
The DILM40 (230V 50HZ, 240V 60HZ) from Eaton Moeller is a three pole contactor with normally open (N/O) contacts. This smart and compact design device has ingenious mechanical interlocks (rocker and ball style) that allow fast and easy assembly of contactor combinations without requiring additional space. It provides isolation and protection from direct hand contact.
- AC-1, AC-3 and AC-4 utilization category
- 230V/50Hz, 240V/60Hz coil voltage
- Rated operational current of 40A (AC-3) and 18A (AC-4) at 380V to 400V
- Rated operational voltage of 690VAC
- Motor rating of 18.5KW (AC-3) and 9KW (AC-4) at 380V to 400V
- 3 pole conventional free air thermal current of 45A at 50Hz/60Hz (AC-1, enclosed)
- IEC/EN 60947-4-1, UL 508, CSA-C22.2, CE and VDE 0660 approved
- Ambient temperature range from -25°C to 60°C (open) and -25°C to 40°C (enclosed)
- IP00 degree of protection
- Breaking capacity of 400A at 380V to 400V
Automation & Process Control, Motor Drive & Control, Industrial
Other details
| Brand | EATON MOELLER |
| Part Number | DILM40 (230V 50HZ,240V 60HZ) |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Manufacturer Catalogue EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
