Description
- Outer Ring: 9x 15W RGBW LEDs Wash Lights
- Center Pixel: 1x 60W RGBW LED for Beams
- DMX, W-DMX, Art-Net, sACN, Kling-Net
- Color Temperature: 2800 to 10,000K
- Pan/Tilt: 540° / 270°
- Motorized Zoom: 7 to 45°
- Virtual Color and Gobo Wheels
- DMX Channels: 26, 66, 113, or 131
- Amphenol XLRnet I/O
- Omega Brackets & Hardware Included
The CHAUVET PROFESSIONAL Maverick MK Pyxis combines an outer ring of nine 15W RGBW (red, green, blue, white) LEDs with one bright, 60W RGBW LED, in a compact moving head fixture. The outer ring offers a 7 to 45° motorized zoom angle and pixel control to produce color washes and beams with variable sizes, while the center pixel comes with a fixed 3° beam angle for dedicated color beam effects. With variable strobe, fast and precise head movements, movement macros, move-in-black functionality, and more, this versatile fixture lets you create light shows with punchy and bold beams, eye-catching aerial and pixel-mapping effects, and multicolored washes in clubs, on concert stages, and more.
The Maverick MK Pyxis can be controlled via DMX, W-DMX, Art-Net, sACN, or Kling-Net protocols. It is equipped with 5- and 3-pin DMX I/O and Amphenol XLRnet through ports I/O for full flexibility in professional environments. The unit is RDM-enabled for remote addressing and troubleshooting, and can convert TCP/IP to DMX for shorter data cable runs. Seetronic Powerkon IP65 I/O connectors provide secure power connections.
Other features include a virtual color wheel with 21 color macros, a built-in virtual gobo wheel, and 0-100% electronic dimming with two dim modes and four dim curves. The Maverick MK Pyxis ships with two Omega brackets and mounting hardware.
- Key Features
-
- Full-featured RGBW LED wash and beam moving head fixture with 360° continuous pan and tilt movement
- Create instant light shows with punchy and bold beams, eye-catching aerial and pixel-mapping effects, and multicolored washes
- Outer ring of nine 15W RGBW LEDs with a 7 to 45° motorized zoom angle and pixel control for wash and narrow effects with variable beam sizes
- Center pixel with a single 60W RGBW LED with a fixed 3° beam angle for dedicated beam color effects
- Virtual Color wheel with instantaneous access to 21 colors
- Built-in color macros for quick design possibilities
- Color temperature 2800 to 10,000K (with presets)
- Built in virtual gobo wheel with background colors for atmospheric effects
- Quiet operation, ideal for use in low-noise environments
- DMX, W-DMX, Art-Net, sACN, Kling-Net control protocols for full flexibility
- DMX Channels: 26, 66, 113, 131 (single mode)
- RDM-enabled for remote addressing and troubleshooting
- Converts TCP/IP to DMX for shorter data cable runs
- True 1 compatible power input
- Battery-powered touchscreen display auto-rotates depending on fixture orientation
- Three setup menu presets and preset sync, for cross-loading to multiple fixtures
- 3- and 5-pin DMX input/output connections
- Amphenol XLRnet through ports I/O
- Daisy-chain power for up to 6 units at 120V or 12 units at 230V
- Multi-voltage operation: 100-240 VAC, auto-ranging
- Rubber feet for positioning fixture on a flat-level surface
- Includes two Omega brackets with mounting hardware
CHAUVET PROFESSIONAL MK Pyxis specs
| Light Source | Outer Ring 9 x 15 W quad-color RGBW (red, green, blue, white) LEDs Current: 1.29 A Center Pixel 1 x 60 W quad-color RGBW (red, green, blue, white) LED Current: 4.5 A |
| LED Life Expectancy | 50,000 hours |
| Color Temperature | 2800 to 10,000K |
| Illuminance | Center Pixel and Outer Ring: 27,560 lux at 16.4' / 5 m Center Pixel: 20,300 lux at 16.4' / 5 m Outer Ring: 7330 lux at 16.4' / 5 m |
| Lumens | Source Center Pixel: 1700 lumens Outer Ring: 4300 lumens Output Center Pixel: 1100 lumens Outer Ring: 2400 lumens |
| Beam Angle | Center Pixel and Outer Ring: 3° Center Pixel: 3° Outer Ring: 5 to 28° |
| Field Angle | Center Pixel and Outer Ring: 6° Center Pixel: 5° Outer Ring: 7 to 45° |
| Zoom Angle | 7 to 45° |
| PWM Frequency | 600, 1200, 2000, 4000, 6000, 15,000 Hz (selectable) |
| Pan/Tilt | 540° / 270° |
| Pan & Tilt Range | Pan: 180, 360, 540°, infinite Tilt: 90, 180, 270°, infinite |
| Color Wheel | 21 colors, virtual |
| Gobo Wheel | Built-in gobos, virtual |
| Dimming | Dimmer: 0-100%, electronic Dim Modes: 2 Dim Curves: 4 |
| Effects | Shutter/Strobe: Electronic, variable from 0 to 20 Hz Motorized zoom 21 x color macros Color temperature presets Move in black |
| Control | Protocol: DMX, W-DMX, Art-Net, sACN, Kling-Net DMX Channels Single Mode: 26, 66, 113, 131 DMX Channels Dual Mode�Function: 13, 26, 33 DMX Channels Dual Mode�Pixel: 30, 40, 80 Art-Net Channels Single Mode: 26, 66, 113, 131 Art-Net Channels Dual Mode�Function: 13, 26, 33 Art-Net Channels Dual Mode�Pixel: 30, 40, 80 |
| Data Connectors | DMX 3-pin I/O DMX 5-pin I/O Amphenol XLRnet through ports I/O |
| Power Linking | 6 units, 13.6 A at 120 V 11 units, 13.6 A at 208 V 12 units, 13.6 A at 230 V |
| Power Requirements | 100-240 VAC, 50/60 Hz (auto-ranging) |
| Power and Current | 262 W, 2.2 A at 120 V, 60 Hz 260 W, 1.2 A at 208 V, 60 Hz 223 W, 1.1 A at 230 V, 50 Hz |
| Fuse | F 5 A, 250 V |
| Power Connections | Input: 1 x Seetronic Powerkon IP65 Output: 1 x Seetronic Powerkon IP65 |
| Power Cord | Edison plug to Seetronic Powerkon IP65 (included) Length: 5' / 1.5 m |
| IP Rating | IP20, dry location |
| Cooling System | Fan-assisted convection |
| Operating Temperature | 13°F / 45°C, maximum external |
| Construction | Housing Material: High-impact, flame-retardant polymer Exterior Color: Black |
| Dimensions | 12.20 x 8.86 x 18.07" / 310.00 x 225.00 x 459.00 mm |
| Weight | 32.0 lb / 14.5 kg |
- Seetronic Powerkon IP65 Power Cord
- 2 x Omega Brackets with Mounting Hardware
- Limited 2-Year Warranty
