Footnotes
Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.
Product details
| End To End Resistance:
100kohm
|
| No. of Pots:
Single
|
| Control Interface:
3 Wire, Serial
|
| Track Taper:
Linear
|
| Resistance Tolerance:
± 20%
|
| Supply Voltage Min:
4.5V
|
| Supply Voltage Max:
5.5V
|
| Potentiometer IC Case Style:
SOIC
|
| No. of Pins:
8Pins
|
| No. of Steps:
100
|
| Temperature Coefficient:
± 300ppm/°C
|
| Operating Temperature Min:
-40°C
|
| Operating Temperature Max:
85°C
|
| Product Range:
Single 100-Tap Non-Volatile Digital Pots
|
| Automotive Qualification Standard:
-
|
| MSL:
MSL 3 - 168 hours
|
Other details
| Brand |
RENESAS |
| Part Number |
X9C104SIZT1 |
| Quantity |
Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |
 |
