The 60L series long life DC Fan designed for use with servers, communications equipment and industrial equipment. The san ace 60L series fans features current cut system with reverse connection motor protection system.
- 50/60Hz, 500VAC Dielectric strength
- 100000/60?C Hours life expectancy
- -10 to +70?C Operating temperature
Applications
Industrial, Thermal Management, HVAC, Communications & Networking
Product details
| Supply Voltage |
24V |
| Current Type |
DC |
| Fan Frame Size |
60mm |
| External Depth |
25mm |
| Flow Rate - Imperial |
18.7cu.ft/min |
| Flow Rate - Metric |
0.53m?/min |
| Noise Rating |
28dBA |
| Bearing Type |
Ball |
| Power Connection Type |
2 Lead Wires |
| Current Rating |
60mA |
| Product Range |
San Ace 60L Series |
| Power Rating |
- |
Other details
| Brand |
SANYO DENKI |
| Part Number |
109L0624H402 |
| Quantity |
Each |
| Technical Data Sheet EN |
 |
