The 9A0924S402 is a 24VDC 25mm thick Axial Fan with ball bearing and wire leaded power connection. This San Ace 92-series 9A-type fan comes with plastic frame and impeller. UL1007, 24AWG +red and -black lead wire. Clockwise direction of rotation viewed from front of fan blade and continuously run in a free air state.
- UL94V-0 Flammability rating
- 3550RPM Speed rating
- -20 to 70°C Operating temperature range
- 3.6W Rated power
- 0.225"-H2O Static pressure
- Ribbed frame
- Current blocking function (with reverse polarity protection)
- 10MR or more at 500VDC Megger (between lead conductor and frame) insulation resistance
- Burnout protection at locked rotor condition
- 1500VAC for one minute Dielectric strength
Warnings Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.
Other details
| Brand |
SANYO DENKI |
| Part Number |
9A0924S402 |
| Quantity |
Each |
| Technical Data Sheet EN |
 |
| Product Change Notice EN |
|
| Manufacturer Catalogue EN |
|
