Description
The TSSP57038TT1 is a 38kHz Compact IR Receiver Module for sensor applications. The detection level does not change when ambient light or strong IR signals are applied. It can receive continuous 38kHz signals or 38kHz bursts.
- �75� Half angle sensitivity
- Low supply current
- Internal filter for PCM frequency
- Improved immunity against ambient light
- Insensitive to supply voltage ripple and noise
Applications
Sensing & Instrumentation, Consumer Electronics
Product details
| Operating Temperature Min | -25�C |
| Directivity | 75� |
| Carrier Frequency | 38kHz |
| Operating Temperature Max | 85�C |
| Product Range | - |
| Supply Current | 700�A |
| Supply Voltage Min | 2.5V |
| Transmission Range | 25m |
| Packaging | Cut Tape |
| Supply Voltage Max | 5.5V |
Other details
| Brand | VISHAY |
| Part Number | TSSP57038TT1 |
| Quantity | Each |
| Technical Data Sheet EN |  |
