Description
GVision USA VW-CG-20HU20AE0 Overview
Set up and view multiple inputs in variable matrix configurations on your video wall or digital signage with this 20 x 20 Video Wall Controller from GVision USA. This 3 RU rack-mounted chassis features an embedded Linux OS that provides stable operation for HDMI video walls with up to 1920 x 1200 displays. This chassis includes 20 HDMI inputs and 20 HDMI outputs and can be configured with optional 4- or 8-input/output HDMI cards in the 10 slots.
The system is designed for 24x7 operation, and it includes EZWall wall client software to set up your video wall configuration. It features window opening, roaming, zoom, PiP (picture-in-Picture), saving layouts, and intelligent temperature control.
Key Features
FPGA architecture and GVision's core image processing strategy provide excellent image processing performance. Embedded Linux OS ensures 24/7 stable operation and protects the device from hackers and viruses.
Plug-in design for boards provides flexible board application and makes the upgrade, expansion and maintenance of the system easier.
Advanced PCIe switching chip in the industry. Each signal has a dedicated transmission channel, which ensures the real-time display of images of all signals. And a service board can be inserted into any service board slot, which allows users to apply boards flexibly.
Resolution Real-time Total Adaptation technology. Each device supports sixteen video walls with different resolutions, and the resolution can be customized.
Supports window opening, roaming, and zooming at any position on the video wall. The unique video processing algorithm ensures that the image quality is not affected during zooming.
Supports "Picture-in-Picture" mode, which allows users to watch videos on top of other windows, presenting flexible layouts.
Supports saving the video wall layout as a scene for later use. Up to 64 scenes can be saved with scene sequence.
Intelligent temperature control design of fans keeps the heat dissipation and noise at an ideal level, and ensures the noise is no more than 30 dBA in conference rooms.
Intelligently monitors board power supply and board temperature. When abnormal board power supply or temperature is detected, the board will automatically shut down to safeguard device operation.
Supports custom EDID, allowing users to customize the resolution of input video sources.
Supports connecting up to 5 board enclosures.
UPC: 801706007221
In the Box
- GVision USA 20 x 20 Video Wall Controller
- Limited 3-Year Manufacturer Warranty
GVision USA VW-CG-20HU20AE0 Specs
| Software Requirements | For EZWall Software: OS: 32-Bit or 64-Bit Microsoft Windows 7, 8, 10 CPU: Intel Core i5 2.3 GHz or Higher RAM: 4 GB or Higher |
| Video Format | 1080p 1920 x 1080: 50, 60 720p 1280 x 720: 50, 60 XGA 1024 x 768: 60 SXGA 1280 x 1024: 60 WXGA 1440 x 900: 60 UXGA 1600 x 1200: 60 WUXGA 1920 x 1200: 60 |
| Video Inputs | 20 x HDMI Type A |
| Video Outputs | 20 x HDMI Type A |
| PCI Slots | 10 |
| Connectors | 1 x RJ45 LAN 1 x RJ45 Console Serial 3 x RJ45 RS-232/RS-485 Serial 2 x USB-A, Keyboard/Mouse 1 x Jack, RST Key 1 x Jack, SWAP Hot-Swappable Key |
| Operating Temperature | 32 to 122°F / 0 to 50°C |
| Operating Humidity | 0 to 90% |
| Storage Temperature | -40 to 158° / -40 to 70°C |
| Storage Humidity | 0 to 95% |
| Voltage | 100 to 240 VAC 50/60Hz |
| Power Consumption | >350 W |
| Dimensions | 17.59 x 18.54 x 5.19" / 471 x 447 x 132 mm |
| Weight | 31.08 lb / 14.1 kg |
