The 1.130.000.033 is a 7-digit Electromechanical Pulse Counter with high shock resistance (AC + DC). It can be used for numerous diverse application areas. It offers base-mount with screw fixing and upright front side display.
- Low power consumption, suitable for battery operation
- Very compact size, large optical figures
- Different viewing possibilities
- Machine solderable and washable
- Stores values if power fails
- Long service life
- IP65 Protection rating
Applications
Industrial, Clock & Timing, Test & Measurement, Security, Consumer Electronics, Medical
Product details
| No. of Digits / Alpha |
7 |
| Digit Height |
4mm |
| Supply Voltage Min |
21.6VDC |
| Supply Voltage Max |
26.4VDC |
| Panel Cutout Height |
13mm |
| Panel Cutout Width |
30mm |
| Operating Temperature Min |
-10?C |
| Operating Temperature Max |
60?C |
| Product Range |
- |
Other details
| Brand |
KUEBLER |
| Part Number |
1.130.000.033 |
| Quantity |
Each |
| Technical Data Sheet EN |
 |
