This is a Trimmer Potentiometer, Top Adjustment, 20 kohm, 1 Turns, Surface Mount Device, ST-4 Series, 250 mW product from NIDEC COPAL ELECTRONICS with the model number ST-4ETA203
Product details
| Track Resistance |
20kohm |
| No. of Turns |
1Turns |
| Potentiometer Mounting |
Surface Mount Device |
| Product Range |
ST-4 Series |
| Power Rating |
250mW |
| Resistance Tolerance |
± 20% |
| Temperature Coefficient |
± 100ppm/°C |
| Automotive Qualification Standard |
- |
| RoHS Phthalates Compliant |
To Be Advised |
Other details
| Brand |
NIDEC COPAL ELECTRONICS |
| Part Number |
ST-4ETA203 |
| Quantity |
Each |
| Technical Data Sheet EN |
 |
