Product details
Inductance Tolerance |
� 10% |
RMS Current (Irms) |
1.4A |
Saturation Current (Isat) |
1.4A |
Power Inductor Case |
12.3mm x 12.3mm x 10mm |
Inductance |
470�H |
Inductor Construction |
Shielded |
Product Range |
MSS1210 Series |
DC Resistance Max |
0.54ohm |
Packaging |
Cut Tape |
Other details
Brand |
COILCRAFT |
Part Number |
MSS1210-474KEB |
Quantity |
Each (Supplied on Cut Tape) |
Technical Data Sheet EN |
|
Product Change Notice EN |
|
