Description
The TOP264VG is a 21W integrated Off-Line Switcher with EcoSmart� technology for highly efficient power supplies. This enhanced EcoSmart� switcher incorporates a 725V power MOSFET, high-voltage switched current source, multi-mode PWM control and oscillator, thermal shutdown circuit, fault protection and other control circuitry onto a monolithic device.
- Energy efficient over entire load range
- Line under-voltage detection prevents turn-OFF glitches
- Line over-voltage shutdown extends line surge limit
- Accurate thermal shutdown with large hysteresis
Applications
Computers & Computer Peripherals, Consumer Electronics, Audio
Product details
| Operating Temperature Min | -40°C |
| Input Voltage AC Max | 265V |
| Operating Temperature Max | 150°C |
| No. of Pins | 12Pins |
| Input Voltage AC Min | 85V |
| Product Range | - |
| Topology | Flyback |
| AC / DC Converter Case Style | DIP |
| Power Rating | 34W |
| Packaging | Cut Tape |
| MSL | - |
Other details
| Brand | POWER INTEGRATIONS |
| Part Number | TOP264VG |
| Quantity | Each |
| Technical Data Sheet EN |  |
