Description
This is a Isolated Board Mount DC/DC Converter, Low Profile, Surface Mount DIP, Fixed, Surface Mount Device product from MURATA POWER SOLUTIONS with the model number NXJ1S1212MC-R7
Product details
| Output Power Max | 1W |
| Input Voltage DC Min | 10.8V |
| DC / DC Converter Mounting | Surface Mount Device |
| Output Voltage - Output 2 | - |
| Output Current - Output 2 | - |
| Depth | 13.72mm |
| Width | 10.46mm |
| Product Range | NXJ1 Series |
| DC / DC Converter Type | Surface Mount DIP |
| Approvals & Standards | - |
| Output Voltage - Output 3 | - |
| Output Voltage - Output 1 | 12V |
| Output Current - Output 3 | - |
| DC / DC Converter Output Type | Fixed |
| No. of Outputs | 1 Output |
| Input Voltage DC Max | 13.2V |
| Output Current - Output 1 | 83mA |
| Height | 4.16mm |
Other details
| Brand | MURATA POWER SOLUTIONS |
| Part Number | NXJ1S1212MC-R7 |
| Quantity | Each |
| Technical Data Sheet EN |  |
