MuxLab HDMI/IP PTZ Camera V2 Overview
Add a standalone video conferencing device to your conference room, lecture hall, event space, or house of worship with this HDMI/IP PTZ Camera with PoE & 30x Zoom V2 from MuxLab. The camera features a high-quality HD 1/2.8" 2.07MP CMOS sensor, 30x optical zoom, a wide 60.7° angle of view, noise reduction, analog audio input, and serial control capability. The camera also features an auto-tracking feature to track your subject as they move.
The PTZ camera allows you to capture up to 1080p60 video that it can output via SDI, USB, HDMI, full NDI, NDI|HX, or IP using high-quality, low-latency H.265/H.264 video codecs. The free-to-download control app installs onto your Android or iOS tablet or Windows system, allowing you to set up and control the PTZ camera. A USB-A port allows you to record your stream onto an optional external drive. Analog audio input and output provides the ability to add external audio to your stream, or to extract audio to a mixer or speakers, and it also features built-in dual mics to add room sound.
The sensor features 2D/3D noise reduction that reduces image noise for a crisp, clean image in low-light. Its quiet motor allows you to pan and tilt smoothly using the included IR remote, via IP connectivity, or via an optional serial controller, using RS-232/485 serial protocols such as VISCA, Pelco-P, and Pelco-D.
Items Included
- MuxLab USB/NDI/IP PTZ Camera with PoE & 30x Optical Zoom V2
- IR Remote Control
- AC Power Adapter
- Power Cord
- RS-232 Cable
- Limited 2-Year Manufacturer Warranty
Additional Resources
MuxLab HDMI/IP PTZ Camera V2 Specs
| Image Sensor |
1/2.8"-Type CMOS
|
| Sensor Resolution |
Effective: 2.07 Megapixel (1920 x 1080)
|
| Shutter Speed |
1/10000 to 1/30 Seconds
|
| Optical Zoom Ratio |
30x
|
| External Recording Modes |
HDMI
1920 x 1080p at 25/30.00/50/59.94/60.00 fps 1920 x 1080i at 50/59.94/60.00 fps 1280 x 720 at 50/59.94/60.00 fps |
| Broadcast Output |
NTSC
|
| IP Streaming |
H.264, H.265, MJPEG, ONVIF, RTMP, RTSP, TCP
1920 x 1080 to 640 x 360 at 1p, 25p, 30p, 50p, 60p (32.00 to 102,400.00 Kb/s) 1280 x 720 to 320 x 180 at 1p, 25p, 30p, 50p, 60p (32.00 to 102,400.00 Kb/s) |
| Supported Control Protocols |
IP
Pelco-D Pelco-P RS-232 |
| PoE Support |
PoE 802.3af
|
| Image Sensor |
1/2.8"-Type CMOS
|
| Sensor Resolution |
Effective: 2.07 Megapixel (1920 x 1080)
|
| Focus Control |
Autofocus
Manual Focus |
| Shutter Speed |
1/10000 to 1/30 Seconds
|
| Signal-to-Noise Ratio |
55 dB
|
| Minimum Illumination |
0.5 Lux
|
| Flip / Mirror Support |
Image Flip, Mirror (Vertical)
|
| White Balance |
Presets: Auto, Indoors, Manual, One Push, Outdoors
|
| Focal Length |
4.42 to 132.6mm
|
| Optical Zoom Ratio |
30x
|
| Field of View |
Horizontal: 60.7 to 2.28°
Vertical: 34.1 to 1.28° |
| Maximum Aperture |
f/1.8 to 2.8
|
| External Recording Modes |
HDMI
1920 x 1080p at 25/30.00/50/59.94/60.00 fps 1920 x 1080i at 50/59.94/60.00 fps 1280 x 720 at 50/59.94/60.00 fps |
| Embedded Audio |
HDMI/LAN (RJ45)/SDI/USB
|
| Broadcast Output |
NTSC
|
| IP Streaming |
H.264, H.265, MJPEG, ONVIF, RTMP, RTSP, TCP
1920 x 1080 to 640 x 360 at 1p, 25p, 30p, 50p, 60p (32.00 to 102,400.00 Kb/s) 1280 x 720 to 320 x 180 at 1p, 25p, 30p, 50p, 60p (32.00 to 102,400.00 Kb/s) |
| IP Multi-Stream Support |
Simultaneous
H.264: 720p |
| Presets |
255
|
| Tally Light |
No
|
| Supported Control Protocols |
IP
Pelco-D Pelco-P RS-232 |
| Video I/O |
1x HDMI 1.3 Output
1x RJ45 LAN Output 1x USB-A 3.0 / 3.1/3.2 Gen 1 Output |
| Audio I/O |
1x 1/8" / 3.5 mm TRS Stereo Line Input
1x 1/8" / 3.5 mm TRS Stereo Line Output |
| Other I/O |
1x Mini-DIN 8-Pin (Pelco-D, Pelco-P, RS-232, VISCA) Control Input
1x Mini-DIN 8-Pin (Pelco-D, Pelco-P, RS-232, VISCA) Control Output 1x Block 2-Pin (RS-485) Control Input |
| Built-In Microphone |
Stereo
|
| PoE Support |
PoE 802.3af
|
| Power I/O |
1x Barrel (12VDC up to 1 A) Input
|
| Power Consumption |
Power Supply: 12 W
|
| Operating Conditions |
14 to 104°F / -10 to 40°C
|
| Storage Conditions |
-40 to 140°F / -40 to 60°C
|
| Environmental Resistance |
No
|
| OS Compatibility |
Windows 7 or Later / macOS 10.11 or Later / Chrome OS / Linux
|
| Dimensions (W x H x D) |
6.6 x 6.7 x 5.7" / 168 x 169 x 146 mm
|
| Weight |
3.3 lb / 1.5 kg (Body Only)
|
