Description
Atomos NEON Overview
- 1Description
- 2The Neon Lineup of Monitor/Recorders
- 3The App
- 4Imaging Tools
- 5Removable Cover Glass
- 6Inputs and Outputs
- 7Video Output
- 8Flexibility
- 9Supported Input Gamma
- 10Supported Input Gamut
- 11Mounting
This Atomos NEON 17" 4K HDR Monitor/Recorder is part of the NEON family of monitor/recorders designed as an accurate and consistent monitoring solution with deep blacks and excellent contrast, as well as ProRes and DNx recording capability. This 17" monitor/recorder features a 1920 x 1080 native resolution while supporting DCI and UHD 4K, as well as 1080p/i and 720p. The monitor provides a clear image well capable of supporting HDR and displaying a 10-bit image that covers 100% of the DCI P3 standard. Its 1000 cd/m² brightness and 128 zones of backlight allow the monitor to achieve a contrast ratio of 1,000,000:1.
The NEON features a Master Control Unit that runs the AtomosOS, controlling the monitor. The Master Control Unit is user-replaceable, so you can have the latest Atomos technology without having to replace the entire monitor. Remote control over your NEON is via a downloadable app and your iOS mobile device. Input your video for display via HDMI or SDI (using the included SDI expansion module) and the monitor displays your video. It can also capture ProRes and DNx to a 2.5" SSD (not included) in the Master Caddy II or to a separately available AtomX SSDmini. The monitor features loop-through and cross conversion outputs, and it supports both Rec 709 and Dolby Vision.
The Neon Lineup of Monitor/Recorders
The App
Imaging Tools
Removable Cover Glass
Inputs and Outputs
Video Output
Flexibility
Supported Input Gamma
- Sony: SLog / SLog2 / SLog3
- Canon: CLog / CLog2 / Clog3
- ARRI: Log CEI160 / LogCEI200 / LogCEI250 /LogCEI320 /LogCEI400 / LogCEI500 / LogCEI640 / LogCEI800/ LogCEI1000 / LogCEI1280 / LogCEI1600
- Panasonic: Vlog
- JVC: JLog1
- RED: RED Log3G10 / RED LogFilm
- FUJIFILM: F-log
- PQ10k
- HLG
Supported Input Gamut
- Sony: SGamut / SGamut3 / SGamut3.cine
- Canon Cinema: / DCI P3 / DCI P3+
- Nikon: NLog
- Panasonic: V Gamut
- ARRI: ALEXA Wide Gamut
- Rec. 709 / BT.2020
- JVC
- RED: WideGamut / DragonColor / DragonColor2 / Color2 / Color3 / Color4
Mounting
In the Box
- Atomos NEON 17" 4K HDR Monitor/Recorder
- Master Control Unit
- Master Caddy II
- AC Power Supply
- AtomX SDI Expansion Module
- 2 x Support Feet (Including Mounting Screws)
- Limited 1-Year Warranty, Extendable to 3 Years with Product Registration
Not in the Box
- Essential Recording Media (Not Included)
- Description
- The Neon Lineup of Monitor/Recorders
- The App
- Imaging Tools
- Removable Cover Glass
- Inputs and Outputs
- Video Output
- Flexibility
- Supported Input Gamma
- Supported Input Gamut
- Mounting
Atomos NEON Specs
| Display Size | 17.0" / 43.2 cm |
| Aspect Ratio | 16:9 |
| Viewing Angle | Horizontal: 180° Vertical: 180° |
| Touchscreen | No |
| Maximum Brightness | 1000 cd/m2 |
| Dynamic Contrast Ratio | 1,000,000:1 |
| Bit Depth / Color Support | 8-Bit+FRC (1.07 Billion Colors) |
| Pixels Per Inch (ppi) | 142 ppi |
| Color Gamut | 100% DCI-P3 |
| Real-Time LUT Monitoring | SDR, HDR |
| Video |
1 x HDMI Type A (HDMI 2.0b) Input 1 x BNC (12G-SDI) Input 1 x HDMI Type A (HDMI 2.0b) Output 1 x BNC (12G-SDI) Output |
| Embedded Audio | HDMI: 8-Channel SDI: 12-Channel |
| Audio | 2 x 1/8" / 3.5 mm Mic/Line Input 1 x 1/8" / 3.5 mm Headphone Output |
| Built-In Speaker | None |
| Card Slot | None |
| Video Format | HDMI (10-Bit) DCI 4K: 60/50/30/25/24 UHD 4K: 60/50/30/25/24 DCI 2K: 120/100/60/50/30/25/24 1080p: 240/200/120/100/60/50/30/25/24 1080i: 60/50 720p: 60/50 |
| Video Signal Conversion | HDMI to SDI DCI 4K: 60/50/30/25/24 UHD 4K: 60/50/30/25/24 1080p: 120/100/60/50/30/25/24 1080i: 60/50 720p: 60/50 SDI to HDMI DCI 4K: 60/50/25/24 UHD 4K: 60/50/30/25/24 1080p: 120/100/60/50/30/25/24 1080i: 60/50 720p: 60/50 |
| Pulldown Conversion | 2:2, 3:2 |
| Camera Trigger | SDI, HDMI |
| Pre-Roll Record | None |
| Encoding Formats | Up to 4096 x 2160 ProRes 422, HQ, LT DNxHR HQ, HQX, LB, SQ |
| Recording Media | 1 x 2.5" SSD (SATA III) |
| Battery Type | None |
| Material of Construction | Aluminum, Polycarbonate |
| Dimensions | 16.3 x 10 x 2.8" / 413 x 253 x 71.4 mm |
| Weight | 9.92 lb / 4.5 kg |
| Warranty Length | Limited 1-Year Warranty |
| Package Weight | 31.7 lb |
| Box Dimensions (LxWxH) | 21.5 x 17.3 x 9.3" |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 151062.1 |
| 3-5 | ₹ 149520.65 |
| 5-10 | ₹ 146437.75 |
| 10+ | ₹ 143354.85 |
Bulk discount will be automatically applied during checkout based on quantity.
