Description
This is a General Purpose Relay, Power PCB Relay RT2 Series, Power, Non Latching, DPDT, 6 VDC, 8 A product from SCHRACK - TE CONNECTIVITY with the model number RTE24006
Product details
| Contact Material | Silver Nickel |
| Relay Mounting | Through Hole |
| Coil Type | Non Latching |
| Coil Resistance | 90ohm |
| Product Range | Power PCB Relay RT2 Series |
| Relay Terminals | Solder |
| Contact Current | 8A |
| Approvals & Standards | CSA, UL, VDE |
| Contact Voltage VAC | 250VAC |
| Coil Voltage | 6VDC |
| Contact Configuration | DPDT |
| Contact Voltage VDC | 30VDC |
Other details
| Brand | SCHRACK - TE CONNECTIVITY |
| Part Number | RTE24006 |
| Quantity | Each |
| Technical Data Sheet EN |  |
