Description
This is a Isolated Board Mount DC/DC Converter, 2 Output, 1 W, 15 V, 33 mA, -9 V, 55 mA product from TRACOPOWER with the model number TMV 12159HI
Product details
| No. of Outputs | 2 Output |
| Output Power Max | 1W |
| Output Voltage - Output 1 | 15V |
| Output Current - Output 1 | 33mA |
| Output Voltage - Output 2 | -9V |
| Output Current - Output 2 | 55mA |
| Output Voltage - Output 3 | - |
| Output Current - Output 3 | - |
| Product Range | TMV-HI Series |
| Input Voltage DC Min | 10.8V |
| Input Voltage DC Max | 13.2V |
| DC / DC Converter Output Type | Fixed |
| DC / DC Converter Type | SIP |
| DC / DC Converter Mounting | Through Hole |
| Approvals & Standards | CAN, CSA, EN, IEC, UL |
| Width | 7.5mm |
| Height | 10.2mm |
| Depth | 19.5mm |
| RoHS Phthalates Compliant | Yes |
Other details
| Brand | TRACOPOWER |
| Part Number | TMV 12159HI |
| Quantity | Each |
| Technical Data Sheet EN |  |
