Description
This 4K HDMI Matrix Switch from Black Box routes 2 HDMI sources to 1 HDMI display. Multi-controlled functions include front-panel buttons with LED indicators, IR remote, and serial control, allowing you to operate the system easily. The 4K HDMI switch can operate in auto mode and priority mode. The system can either automatically select the latest video source for display in auto mode, or automatically select a video source following priority order in priority mode. It also offers EDID copy function to ensure the optimal resolution for your application. The built-in serial interface allows users to control the HDMI Matrix through a PC, serial controller devices, or home theater system, integrating the whole A/V environment.
- Supports 2 displays as input and 1 HDMI display as output
- Supports resolutions up to full HD 1080p/4K
- Non-volatile memory stores all settings in case of blackout
- Auto-sensing function automatically selects active input source or prioritized source
- Control the switch via the front-panel push button or IR remote controller (included)
- Individually turn ON/OFF the output port
- Optimizes signals by choosing the best output setting from the available alternatives
- Compatible with HDTV and 3D HDTV
- Complies with HDCP standard
- Power Adapter
- IR Remote Controller
- Set of Foot Pads
- Limited 1-Year Warranty
| Frequency Range | 25 to 297 MHz |
| Resolution | Maximum 4K @ 30 Hz |
| Modes | Switch / Autosensing / Priority / Matrix |
| MTBF | 50,000 hours |
| EDID | Configuration: Video: Auto/inventory Audio: Auto/inventory |
| User Control | Port selection switch button, EDID copy button, EDID switch for EDID selection, EGO setting switch for auto functions |
| HDMI | Port Type: Female 2 x Input 1 x Output |
| Serial Port | 1 x RJ-12 female |
| Power | 100 to 240 VAC, 50 to 60 Hz, 45 W 9 to 12 VDC (power adapter included) |
| Indicators | 2 x LEDs for input status |
| Approvals | FCC Part 15, CE, UL, RoHS, CSA, TUV |
| Operating Temperature | 32 to 104�F (0 to 40�C) |
| Storage Temperature | -4 to 140� F (-20 to 60� C) |
| Relative Humidity | 80% |
| Altitude | 10,000' (3048 m) |
| Dimensions | 0.8 x 6.1 x 2.6" (2.0 x 15.6 x 6.5 cm) |
| Weight | 1.55 lb (0.7 kg) |
| Packaging Info | |
|---|---|
| Package Weight | 2.0 lb |
| Box Dimensions (LxWxH) | 9.2 x 6.1 x 2.7" |
