Description
Digital Watchdog DWC-PDS10WI28A Overview
Monitor your surroundings with the MEGApix Ai 10MP Dual-Sensor Outdoor Network Dome Camera from Digital Watchdog. This multi-sensor camera uses two 1/2.8" 5MP CMOS sensors to capture video at a combined resolution of 10MP at 30fps. The camera is equipped with two 2.8mm fixed lenses that each deliver a 102.4° horizontal field of view. Two-way audio is possible thanks to a built-in microphone and an audio output. An onboard slot accepts microSD/SDHC/SDXC cards (available separately). Integrated PoE technology simplifies connectivity by transferring data and power through a single cable.
Compliance with ONVIF profile S enables interoperability with a wide range of surveillance devices. This camera is housed in an IP67- and IK10-rated enclosure that is suitable for safe outdoor use in areas at risk of vandalism.
Dual-sensor camera in a single body
Simple setup with no analytics calibration
Star-Light Plus technology for visibility in low-light conditions
Mechanical IR cut filter for true day and night switching
CBR and VBR
Motion detection
Deep learning object tracking with analytic filters that include: zones and lines, tamper, metadata, intrusion, line crossing, counting, counting lines, appear, disappear, stopped, enter, exit, direction, tailgating, dwell, and logical rules
Ai Deep Learning object detection on one channel
Create up to 40 detection zones in the same camera
180° hallway and 90° corner panoramic views
Seamless integration and control with DW Spectrum IPVMS
Alarm sensor input and relay output
Additional features include: built-in web server, 16 programmable privacy masks, mirror/flip perspectives, 120 dB wide dynamic range, 50 dB S/N ratio, 3D-DNR, automatic gain control, and auto white balance
NDAA and TAA compliant
In the Box
- Digital Watchdog MEGApix Ai 10MP Dual-Sensor Outdoor Network Dome Camera
- Limited 5-Year Manufacturer Warranty
Digital Watchdog DWC-PDS10WI28A Specs
Key Specs
| Sensor |
2 x 5 MP 1/2.8" CMOS
|
| Focal Length |
2.8mm
|
| Lens Field of View |
Horizontal: 102.4°
Vertical: 77.4° |
| Video Outputs |
1 x BNC (Composite)
|
| Built-In Mic |
Yes
|
| Power Source |
DC, PoE 802.3af (15 W)
|
| Environmental Protection |
Advertised as Dust Resistant/Outdoor Use/Water Resistant
*Manufacturer Testing: IP67 |
| Illumination |
IR LEDs up to 60' / 18.3 m
|
Camera
| Sensor |
2 x 5 MP 1/2.8" CMOS
|
| Focal Length |
2.8mm
|
| Maximum Aperture |
f/1.8
|
| Lens Field of View |
Horizontal: 102.4°
Vertical: 77.4° |
| IR Cut Filter |
Mechanical
|
| Day/Night |
True
|
| Minimum Illumination |
Color: 0.13 Lux
B&W: 0 Lux |
| Shutter Speed |
1/32000 to 1/15 Seconds
|
| Mobile App Compatible |
Yes: Android & iOS
App Name: DW Spectrum IPVMS *As of November, 2023: Check with manufacturer for the most up-to-date compatibility |
Video
| Streaming Resolution |
2592 x 1944 at 30 fps (25 Mb/s )
|
| Supported Video Compression |
H.264, H.265, MJPEG
|
| Multi-View Streaming |
Yes, 2 Streams
|
| Automatic Gain Control |
Yes
|
| Video Outputs |
1 x BNC (Composite)
|
Audio
| 1- or 2-Way Audio |
Two-Way
|
| Audio Formats |
G.711
|
| Built-In Mic |
Yes
|
Networking
| Security |
Digest Authentication, HTTPS, IEEE 802.1X, IP Address Filtering
|
| Supported Protocols |
APIPA, DDNS, DHCP, DNS, FTP, HTTP, ICMP, IPv4/v6, NTP, RTP, RTSP, SMTP, SNMP v1/v2c/v3 (MIB-II), SSL/TLS, TCP, UDP
|
System Integration
| Application Programming Interface (API) |
ONVIF Profile S
|
| Analytics |
Motion Detection, Deep Learning Object Tracking
|
| OS Compatibility |
Windows
macOS Linux |
Sensors & Alarms
| Event Trigger |
Yes
|
| Event Action |
Recording, Notification, Alarm
|
| Data Streaming |
Yes
|
| Alarm I/O |
1 / 1
|
Hardware
| Media/Memory Card Slot |
Single Slot: microSD/microSDHC/microSDXC [Class 10/U1/V10 or Faster Recommended]
|
| Internal Storage |
No
|
Power
| Power Source |
DC, PoE 802.3af (15 W)
|
| Power Consumption |
DC: 9.9 W
PoE: 11.6 W |
Environmental
| Operating Temperature |
-4 to 122°F / -20 to 50°C
|
| Operating Humidity |
10 to 90% (Non-Condensing)
|
| Environmental Protection |
Advertised as Dust Resistant/Outdoor Use/Water Resistant
*Manufacturer Testing: IP67 |
| IK Rating |
IK10
|
General
| Inputs/Outputs |
1 x RJ45
1 x Power |
| Illumination |
IR LEDs up to 60' / 18.3 m
|
| Video Management Software |
DW Spectrum IPVMS
|
| Certifications |
FCC (Part 15 Class B), RoHS, UL, as per Manufacturer
|
| Material of Construction |
Aluminum, Polymer
|
| Dimensions |
ø: 5.5 x H: 3.1" / ø: 139.0 x H: 79.5 mm
|
| Weight |
1.5 lb / 0.68 kg
|
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
