Description
This is a POWER RELAY, DPST-NO, 18VDC, 30A, FLANGE product from POTTER&BRUMFIELD - TE CONNECTIVITY with the model number T92S7D22-18.
Product details
| Contact Material | Silver Cadmium Oxide |
| Relay Mounting | Panel |
| Coil Type | Non Latching |
| Coil Resistance | 197ohm |
| Product Range | T92 Series |
| Relay Terminals | Quick Connect |
| Contact Current | 30A |
| Approvals & Standards | CSA, UL, VDE |
| Contact Voltage VAC | 277VAC |
| Coil Voltage | 18VDC |
| Contact Configuration | DPST-NO |
| Contact Voltage VDC | 28VDC |
Other details
| Brand | POTTER&BRUMFIELD - TE CONNECTIVITY |
| Part Number | T92S7D22-18. |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 2210.52 |
| 3-5 | ₹ 2187.96 |
| 5-10 | ₹ 2142.85 |
| 10+ | ₹ 2097.74 |
Bulk discount will be automatically applied during checkout based on quantity.
