AIM-TTI INSTRUMENTS PSA6005 Spectrum Analyser, Handheld, PSA Series 5, 10MHz to 6GHz, 192 mm, 92 mm, 49 mm GTIN UPC EAN: 5060584590323

The PSA6005 is a 6GHz handheld RF Spectrum Analysers incorporates bench-top level features within in a portable spectrum analyser. The PSA series 5 is sufficiently small and lightweight to fit comfortably into the hand - unlike most other so called handheld spectrum analysers. A removable screen protector and sun-shield combines with rubberised buffers top and bottom to enhance its use in the field. The 4.3-inch TFT display provides a wealth of detailed information. Colour is used to clearly distinguish between multiple traces, markers and limit lines. The touch-screen uses a three row hierarchical menu system to provide fast and intuitive control of the many functions. It operates from a Li-ion rechargeable battery that can provide more than 3hrs of continuous operation. If switched-OFF to conserve power, it returns to normal operation within a few seconds of switch-ON with all data retained. It can also be set to switch-OFF automatically after a set time from the last action.

• Resolution bandwidths from 300Hz to 10MHz (1:3:10)
• -120dBm typical noise floor at -40dBm ref. level/10kHz RBW
• Measurement in dBm or dBµV, mV or µW
• Zero span mode with AM and FM audio demodulation
• Trace modes of normal, peak hold and trace average
• Live, View and Reference traces in contrasting colours
• Twin markers with readout of absolute and difference values
• Smart marker movement with selectable peak tracking
• Frequency counter with down to 10Hz resolution
• Frequency presets and independent state storage
• Auto-find automatically sets sweep parameters for the highest signal found
• Unlimited storage for waveforms, set-ups and screens
• User-assignable file names, file stamping from real-time clock
• USB interfaces for Flash drives and PC connection
• Comprehensive status and context sensitive help screens
• Rechargeable lithium-ion battery giving more than 3 hours continuous operation

Applications

Test & Measurement, Industrial, RF Communications, Communications & Networking, Portable Devices

In addition, we have calibration services for this product (Europe Only). Visit our calibration service page to see details of what options are available.
