Description
The 7490100111A from Wurth Elektronik is a SMD type LAN transformer. This device complies with IEEE 802.3u standard for 10/100Base-TX-applications.
- Minimum inductance is 350µH
- Turn ratio is 1:1
- Operating temperature range from -40°C to 105°C
- Auto MDIX capable
- Size 12.7mm x 9.4mm x 6mm
- Insertion loss is -1.1dB at 1MHz to 100MHz
- Minimum return Loss is -10dB at 100MHz
- Crosstalk is -38dB at 1MHz to 100MHz
- Differential to common mode rejection is -38dB at 1MHz to 100MHz
Industrial, Power Management, Communications & Networking
Warnings Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.Other details
| Brand | WURTH ELEKTRONIK |
| Part Number | 7490100111A |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
| Product Change Notice EN | |
