| ₹ 6074.31 includes GST and import duties. | |
| B2B customers can avail ₹ 926.33 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
The HF365/04SF is a 100ft 4-conductor splice-free Flat Ribbon Cable, 28AWG wire on 0.050-inch centers permits mass termination to broad line of IDC connectors. The HF365 series flat cable is made of round tinned copper conductor, dark grey halogen free polyolefin jacket. The advantages of LSZH insulation are the low smoke (IEC 61034-2:2005) and low toxicity of combustion gases (NF X 70-100-2:2006), reducing the risk to firefighters and reducing the soot and corrosion damage to nearby equipment.
- Zippable for branching or discrete terminations
- Broad operating temperature range from -40�C to 105�C
- 100R Unbalanced, 168R balanced characteristic impedance
- UL Horizontal flammability rating
Applications
Industrial
Product details
| No. of Cores | 4Core |
| Reel Length (Metric) | 30.5m |
| Conductor Material | Tinned Copper |
| Pitch Spacing | 1.27mm |
| Jacket Material | Polyolefin, Zero Halogen |
| Voltage Rating | 50V |
| Cable Width | - |
| Reel Length (Imperial) | 100ft |
| Product Range | HF365 Series |
| Wire Gauge | 28AWG |
| Jacket Colour | Grey |
| No. of Max Strands x Strand Size | 7 x 0.127mm |
| Conductor Area CSA | - |
| Ribbon Cable Type | Flat Ribbon Cable |
Other details
| Brand | 3M |
| Part Number | HF365/04SF |
| Quantity | Reel of 100 |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 5952.82 |
| 3-5 | ₹ 5892.08 |
| 5-10 | ₹ 5770.59 |
| 10+ | ₹ 5649.11 |
Bulk discount will be automatically applied during checkout based on quantity.
