| ₹ 106435.0 includes GST and import duties. | |
| B2B customers can avail ₹ 16231.34 ITC on this product | |
| 100% Secure Payments | 100% Genuine product | |
| The product is eligible for Free Shipping |
Description
- 2048 x 1536 Resolution at 20 fps
- 1.9mm Fixed Lens
- 126.9° Field of View
- Two-Way Audio
- microSD Slot for Local Storage
- RJ45 Ethernet Connection with PoE
- ONVIF-Compliant
- IP68- and NEMA 4X-Rated for Outdoor Use
- IK10-Rated for Vandal Resistance
The E918 3MP Outdoor Network Dome Camera from ACTi features a 3MP 1/3" progressive scan CMOS sensor to capture 2048 x 1536 resolution video at up to 20 fps. This camera features an RJ45 Ethernet connection with PoE and compresses video in H.264 and MJPEG codecs to ensure high-quality recording and playback. The camera is housed in an IP68-, NEMA 4X-, and IK10-rated housing for protection against dust, water, corrosion, and impact.
- 3MP image sensor captures 2048 x 1536 resolution video at up to 20 fps
- 1.9mm fixed lens has a wide 126.9° field of view to monitor large areas
- Wide dynamic range of up to 110 dB
- IP68-, NEMA 4X-, and IK10-rated housing for outdoor use
UPC: 888034004733
| Device | |
|---|---|
| Image Sensor | 3.15 MP 1/3" progressive scan CMOS sensor |
| Effective Pixels | 2048 x 1536 |
| Minimum Illumination | Color: 0.1 lux at f/2.8 (30 IRE, 2400K) |
| Electronic Shutter | Manual Mode: 1/5 to 1/2,000 s Auto Mode: 1/5 to 1/10,000 s |
| TV Lines | 1250 TVL |
| S/N Ratio | 52 dB |
| Lens | |
|---|---|
| Focal Length | 1.9mm |
| Aperture | f/2.8 |
| Iris | Fixed iris |
| Lens Mount | Board mount |
| Field of View | Overview Area: 126.9° High Detail Area: 77.4° |
| Viewing Angle Adjustment | Pan: ±90° Tilt: 0 to 90° |
| Video | |
|---|---|
| Frame Rates | 20 fps at 2048 x 1536 30 fps at 1920 x 1080 30 fps at 1280 x 720 30 fps at 640 x 480 15 fps at 320 x 240 |
| Compression | H.264 (baseline, main, high profile) and MJPEG |
| Multi-Streaming | Simultaneous dual streams based on two configurations |
| Bit Rate | 28 kb/s to 6 Mb/s (per stream) |
| Bit Rate Mode | Constant, variable |
| Image Enhancement | Superior WDR (110 dB), white balance (automatic, hold, manual), brightness, contrast, sharpness (auto), auto gain control, digital noise reduction, flickerless |
| Privacy Masking | 4 configurable regions |
| Text Overlay | User defined text on video |
| Image Orientation | Image flip and mirror |
| Audio | |
|---|---|
| Audio In | Mic in and line in, cable with 3.5 mm phone jack |
| Network | |
|---|---|
| Protocols Supported | TCP, UDP, HTTP, HTTPS, DHCP, PPPoE, RTP, RTSP, IPv6, DNS, DDNS, NTP, ICMP, ARP, IGMP, SMTP, FTP, UPnP, SNMP, Bonjour |
| Ethernet Port | 1 x RJ45 Ethernet 10/100Base-T |
| Security | IP address filtering; HTTPS encryption; Password protected user levels; Anonymous login; IEEE 802.1X network access control |
| Alarm | |
|---|---|
| Alarm Triggers | Video motion detection (3 regions) |
| Alarm Response | Notify control center, change camera settings, command other devices, email notification with snapshots, save video or snapshot to local storage, upload video, snapshot to FTP |
| Interface | |
|---|---|
| Local Storage | microSDHC/SDXC card slot |
| Integration | |
|---|---|
| Unified Solution | Fully compatible with ACTi software |
| ISV Integration | Software Development Kit (SDK) available, ONVIF-compliant |
| Firmware Access Browser | Microsoft Internet Explorer 8.0 or newer (full functionality); Safari with QuickTime installed, and other browsers with VLC installed (partial functionality) |
| General | |
|---|---|
| Power Source | PoE Class 2 (IEEE802.3af) |
| Consumption | 3.84 W |
| Enclosure | IP68, NEMA 4X, and IK10 |
| Starting Temperature | -4 to 122°F (-20 to 50°C) |
| Operating Temperature | -4 to 122°F (-20 to 50°C) |
| Operating Humidity | 10 to 85% RH |
| Approvals | CE (EN 55022 Class B, EN 55024), FCC (Part 15 Subpart B Class B), IK10, IP68, NEMA 4X, EN50155 |
| Dimensions | 4.3 x 2.3" (11 x 5.8 cm) |
| Weight | 0.9 lb (0.4 kg) |
| Packaging Info | |
|---|---|
| Package Weight | 1.8 lb |
| Box Dimensions (LxWxH) | 7.9 x 7.8 x 3.5" |
In the Box
ACTi E918 3MP Outdoor Network Dome Camera
- Screw Kit
- Cable Gland
- Drill Template
- Hexagon Screwdriver
- Limited 3-Year Warranty
Bulk Discount
| Quantity | Price |
| 2 | ₹ 104306.3 |
| 3-5 | ₹ 103241.95 |
| 5-10 | ₹ 101113.25 |
| 10+ | ₹ 98984.55 |
Bulk discount will be automatically applied during checkout based on quantity.
