AM6CW-4805S-NZ is an AM6CW-NZ series 6W DC-DC converter. It features wide 4:1 input voltage range. It includes over current protection, output over voltage protection, continuous short circuit protection, input under voltage protection. Certified by UL, EN/IEC/UL60950-1, EN50155.
- Input voltage range from 18 to 75V, output voltage is 5V
- Maximum output current is 1200mA, isolation is 1500VDC
- Efficiency is 83%
- Typical switching frequency is 300KHz(100% load)
- Aluminium alloy case material
- Operating temperature range from -40°C to +85°C
- Dimensions (L x W x H) is 25.40 x 25.40 x 11.70mm
Other details
| Brand |
AIMTEC |
| Part Number |
AM6CW-4805S-NZ |
| Quantity |
Each |
| Technical Data Sheet EN |
 |
