Description
American DJ ElectraPix Par 7 Overview
Light up your next indoor / outdoor event with the American DJ ElectraPix Par 7, an innovative wireless DMX lighting solution that's packed with advanced features to provide unparalleled control and creativity. The ElectraPix Par 7 is powered by seven 20W RGBAL+UV LEDs and 29 0.2W RGB background LEDs with individual pixel control for incredibly dynamic lighting possibilities. Its color-calibrated LEDs, user-selectable dim modes, and electronic strobe/dimming enhance versatility.
Designed for adaptability, the IP65-Rated housing, OLED digital display, L Track system, and adjustable feet make installation and customization a breeze. The fixture's control options include DMX512, Aria X2 Wireless DMX, Bluetooth, RDM compatibility, and an included UCIR24 wireless remote. The fixture is powered by either batteries or wall outlets and offers 5 hours of standard battery operation or an extended 10-hour saver mode. The ElectraPix Par 7 ships with an outdoor locking power cable, a gel frame, and a 20° diffusion filter.
- 7-pixel hex color LED (RGBAL+UV) LED Par
- Battery or wall powered
- 5-hour standard battery operation and 10-hour saver battery operation (menu option)
- Individual pixel control
- Built-in foreground LED programs
- Built-in background LED programs
- Variable white color temperature control (2700 to 9900k)
- English and Spanish user menu
- Built-in alarm
- Color calibrated LED's
- User selectable led refresh rates (900 Hz to 25 kHz)
- 6-user selectable dim modes
- 4-user selectable dim curves
- Electronic strobe (0.3 to 11 Hz)
- Electronic dimming
- DMX512
- Aria X2 wireless DMX
- Bluetooth
- RDM and RDM Net compatible
- Includes UCIR24 wireless remote
- DMX: 5, 6, 9, 13, 22, 24, 42, 45, and 54 channel modes
- Onboard manual control mode
- Primary / secondary mode
Connections:
- 5-pin XLR outdoor DMX in/out sockets (must be used with STRxxx, 5-pin DMX cables to create IP65 seal)
- Outdoor locking power sockets
- Battery charging socket
Items Included
- American DJ ElectraPix Par 7 IP65 Outdoor-Rated Battery Powered RGBAL+UV LED PAR
- Outdoor Locking Power Cable
- UCIR24 Remote
- Gel Frame
- 20° Diffusion Filter
- Limited 2-Year Manufacturer Warranty
Additional Resources
Guides & Manuals
American DJ ElectraPix Par 7 Specs
| Fixture Type |
PAR
|
| Light Source |
7x Color LED - 20 W
29x Color LED - 0.2 W |
| Colors |
Amber, Blue, Green, Lime, Red, Ultraviolet
|
| Pixel Configuration |
7x Zone
|
| Beam Angle |
17°
|
| Control Protocols |
DMX512, RDM, WiFly
|
| AC Input Power |
100 to 240 VAC, 50/60 Hz
|
| Power / Current Consumption |
60 W
|
| Mounting |
Dual/Scissor Yoke
|
| Fixture Type |
PAR
|
| Light Source |
7x Color LED - 20 W
29x Color LED - 0.2 W |
| Expected Lamp Life |
50,000 Hours
|
| Colors |
Amber, Blue, Green, Lime, Red, Ultraviolet
|
| Pixel Configuration |
7x Zone
|
| Color Temperature |
2300 to 9900K
|
| Beam Angle |
17°
|
| Shutter / Strobe |
Electronic
|
| Iris |
No
|
| Zoom Adjustment |
Motorized, 5 to 30°
|
| Operating Modes |
Color Dimmer, DMX, Primary/Secondary, Program, Static Color
|
| Macros / Programs |
Color Macro
|
| Effects |
Strobe
Pulse |
| Strobe Rate |
0.3 to 11 Hz
|
| Gobos |
No
|
| Refresh Rate |
900 Hz to 25,000 Hz
|
| Control Protocols |
DMX512, RDM, WiFly
|
| DMX Channel Modes |
9 Mode(s):
5 / 6 / 9 / 13 / 22 / 24 / 42 / 45 / 54-Channel |
| Display / Controls |
OLED / 4-Button
|
| Remote Control |
No
|
| Mobile App Compatible |
No
|
| Inputs/Outputs |
1 x XLR 5-Pin DMX Input
1 x XLR 5-Pin DMX Output |
| Wireless |
Wi-Fi
*Built-In |
| AC Input Power |
100 to 240 VAC, 50/60 Hz
|
| AC Power Connector |
Input: 1x Seetronic IP-Rated
Output: 1x Seetronic IP-Rated |
| Power / Current Consumption |
60 W
|
| Power Linking |
15 Units at 120 VAC
28 Units at 230 VAC |
| Battery Type |
22.2 V Lithium-Ion
|
| Battery Capacity |
7000 mAh
|
| Approximate Battery Life |
All On: Up to 5 Hours
Energy Saving: Up to 10 Hours |
| Battery Charging Time |
6 Hours
|
| Environmental Resistance |
Dust/Water-Resistant (IP65)
|
| Mounting |
Dual/Scissor Yoke
|
| Included Accessories |
1x Power Cable
1x Filter 1x Gel Frame |
| Duty Cycle |
No
|
| Exterior Color |
Black
|
| Certifications |
CE, cETLus, FCC
|
| Dimensions |
11.11 x 9.77 x 7.46" / 28.22 x 24.82 x 18.95 cm
|
| Weight |
15.4 lb / 7 kg
|
