| ₹ 128.26 includes GST and import duties. | |
| B2B customers can avail ₹ 19.56 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
- UL94H-B Flammability rating
- 12V Voltage rating
- -30 to +105�C Temperature range
- 22 to 20AWG Wire range
Applications
Automotive, Industrial
Product details
| No. of Contacts | 16Contacts |
| Contact Plating | - |
| Gender | Plug |
| Product Range | MULTI-LOCK 40 Series |
| Contact Material | - |
| Contact Termination Type | - |
| Pitch Spacing | 2.5mm |
| No. of Rows | 2Rows |
Other details
| Brand | AMP - TE CONNECTIVITY |
| Part Number | 174046-2 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Drawing EN | |
| Operating Instructions EN | |
| 3D Product Image EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 125.69 |
| 3-5 | ₹ 124.41 |
| 5-10 | ₹ 121.85 |
| 10+ | ₹ 119.28 |
Bulk discount will be automatically applied during checkout based on quantity.
Customer Reviews
I bought this for my yamaha r15 meter console. The original one broken and i didn’t wanted to replace the whole wiring of the bike which is expensive and also a tough job for the little damage. So I searched google and found that the ninja 300 has also the same connector. I searched for 3 days and out of 1 million connector I found what I exactly needed. I found the part number which was 174046-2 and Thanks for the 3d model which was helpful to confirm the exact connector which I was looking for.
