Description
AVPro Edge MXNET-1G-EV2 Overview
- 1Description
- 2AVPro Edge ASIC
- 3JPEG 2000
- 4Up to UHD 4K60 Support
- 5High-Bitrate Audio Support
- 6OLED Window
- 7NetGear Support
The MXNet 1G Evolution II Encoder from AVPro Edge receives and encodes HDMI 2.0 video and audio signals at resolutions up to DCI 4K60 4:4:4, along with control, power, and HDR metadata. This encoder supports HDR10, HLG, and Dolby Vision up to 30 Hz and is designed for use with an MXNet switch or a multicast capable L3 switch and with Cat 6A cable or with SFP fiber for longer runs. It features a new AVPro Edge ASIC (application-specific integrated circuit) for enhanced video processing and support for audio formats like Dolby Atmos and DTS:X for IMAX Enhanced soundtracks.
Note:
The AC-MXNET-1G-EV2 may coexist alongside 1st-generation MXNet encoders and decoders within previously installed or pending systems; however, they are required to be used exclusively in EVO II transmitter-to-EVO II decoder(s) pairings only.
AVPro Edge ASIC
The AVPro Edge ASIC (application-specific integrated circuit) substantially improves the fidelity of the decoded image.
JPEG 2000
- The JPEG 2000 encoding used by MXNet components optimizes compression efficiency for applications with limited bandwidth.
- Provides both lossless or lossy compression and parsable code streams.
- Genlock support for syncing a video source to decoders comprising a video wall for a tear-free screen appearance.
Up to UHD 4K60 Support
- This Evolution II Encoder supports video resolutions up to DCI 4K60 4:4:4/4:2:2 12-bit signals using limited, ultralight ICT compression.
- Supports up to DCI 4K60 4:4:4 8-bit and UHD 4K60 4:2:2 12-bit uncompressed video signals.
- Supports HDR 10, HLG, and Dolby Vision up to DCI 4K30.
High-Bitrate Audio Support
- The Evolution II Encoder supports multichannel, high-bitrate audio.
- Supports audio formats like Dolby Atmos and DTS-X for IMAX Enhanced soundtracks and more.
OLED Window
- The front-panel OLED screen displays critical information, making setup and troubleshooting easier.
- The data window displays the IP address and the MAC address or can be modified to display up to 12-character custom names.
NetGear Support
- Install the AVPro Edge Profile for seamless compatibility with NetGear switchers.
UPC: 810108230076
In the Box
- AVPro Edge MXNet 1G Evolution II Encoder
- Power Supply
- Limited 10-Year Manufacturer Warranty
Guides & Manuals
Table of Contents
- Description
- AVPro Edge ASIC
- JPEG 2000
- Up to UHD 4K60 Support
- High-Bitrate Audio Support
- OLED Window
- NetGear Support
AVPro Edge MXNET-1G-EV2 Specs
Inputs / Outputs
| Video Inputs |
1x HDMI (2.0) Female
|
| Audio Inputs |
1x 1/8" / 3.5 mm TRS Female
|
| Video Outputs |
1x RJ45 (DVI) Female
1x LC Fiber (DVI) Female 1x HDMI (2.0b) Female (Loop Output) |
| Audio Outputs |
1x Block 5-Pin Stereo Female
|
| Other I/O |
2x 1/8" / 3.5 mm IR Input
1x 1/8" / 3.5 mm IR Output 1x Block 3-Pin RS-232 Input/Output 1x USB-B 1x USB-C |
| Expansion Slots |
No
|
Format Support
| Input Video Format |
Fiber / RJ45 (8-Bit 4:4:4 RGB, YCC)
DCI 4K at 60 fps Fiber / RJ45 (10/12-Bit 4:4:4/4:2:2/4:2:0 RGB, YCC) UHD 4K at 24/30/50/60 fps Fiber / RJ45 (10/12/16-Bit) 1080p at 50/60 fps 720p at 50/60 fps |
| Output Video Format |
Fiber / HDMI / RJ45 (8-Bit 4:4:4 RGB, YCC)
DCI 4K at 60 fps Fiber / HDMI / RJ45 (10/12-Bit 4:4:4/4:2:2/4:2:0 RGB, YCC) UHD 4K 24/30/50/60 fps Fiber / HDMI / RJ45 (10/12/16-Bit 4:4:4/4:2:2/4:2:0 RGB, YCC) 1080p at 50/60 fps 720p at 50/60 fps |
| Output Audio Format |
Analog
|
| Embedded Audio |
Fiber/HDMI/LAN (RJ45)
|
Standards
| HDCP Support |
Yes, Version 2.3
|
| HDR Compatibility |
HDR10, Hybrid Log Gamma
|
| DTS Compatibility |
DTS, DTS-ES, DTS-HD High Resolution
|
| Dolby Compatibility |
Dolby Digital, Dolby Digital Plus
|
Hardware
| Tally Light |
Yes
|
| Wireless |
No
|
Power
| Power I/O |
1x Barrel (12 VDC at 2 A) Output
|
| PoE Support |
PoE 802.3af
|
| Power Consumption |
9.5 W
|
Environmental
| Operating Temperature |
23 to 125°F / -5 to 51°C
|
| Storage Temperature |
-4 to 140°F / -20 to 60°C
|
| Operating Humidity |
5 to 90% ()
|
General
| Certifications |
CE, FCC, UL
|
| Dimensions |
7.9 x 4.7 x 0.8" / 200 x 120 x 20 mm
|
| Weight |
1.2 lb / 550 g
|
