The 3269W-1-103LF is a 10kR 250mW 1/4-inch square SMD Trimming Potentiometer with 100% tin-plated terminations. The Trimpot® trimming potentiometer features stable, infinite resolution cermet element and 12 turns nominal adjustment angle. Compatible with surface mount manufacturing processes.
- Wiper idles mechanical stop
- 200-cycle Rotational life
- -65 to 150°C Temperature range
Footnotes Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.
Other details
| Brand |
BOURNS |
| Part Number |
3269W-1-103LF |
| Quantity |
Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |
 |
| CAD Multiple Formats EN |
|
| 3D Product Image EN |
|
