Description
BZBGear BG-12GS Overview
The 12G-SDI 1 x 8 Splitter/Distribution Amplifier from BZBGear supports up to 4K video and features eight separately buffered and reclocked outputs to help eliminate jitter and extend transmission distances. It provides automatic input cable equalization up to 591' at 3G-SDI, 330' at 6G-SDI, or 230' at 12G-SDI. Housed in a durable metal casing, this compact DA has LED indicators displaying the signal lock and video rate, as well as a locking power supply connector.
Supports up to 12G-SDI Video
- Distributes one source to a maximum of eight displays
- Supports 12G/6G/3G/HD/SD-SDI video at rates up to 4K
- Automatically detects, reclocks, and regenerates the signal
- LED signal lock and rate display
Durable Design
- Rugged metal housing stands up to repeated use
- Locking connector prevents power loss
UPC: 850023208163
In the Box
- BZBGear 12G-SDI 1 x 8 Splitter/Distribution Amplifier
- 5V Power Adapter
- BNC 75-Ohm Terminator
- Limited 3-Year Warranty
BZBGear BG-12GS Specs
Interfaces
| Input Connectors | 1 x BNC (12G-SDI / 6G-SDI / 3G-SDI / HD-SDI / SD-SDI / DVB-ASI) |
| Embedded Audio Input | SDI |
| Output Connectors | 8 x BNC (12G-SDI / 6G-SDI / 3G-SDI / HD-SDI / SD-SDI / DVB-ASI) |
Standards
| Video Standard Compliance | SMPTE 259M/292M/344M/424M/ST-2081/ST-2082 |
| Reclocking | Yes |
| HDR Compatibility | None |
| HDCP Support | None |
| EDID Support | None |
Transmission
| Max Transmission Distance | DCI 4K: 230' / 70.1 m UHD 4K: 330' / 100.6 m 1080p: 591' / 180.1 m |
| Bandwidth | 10 Hz to 1188 MHz |
| Impedance | 75 Ohms (Output) |
| Jitter | < 1 UI |
| Maximum Data Rate | 11.88 Gb/s |
Power
| Power Connector | 1 x Barrel (5 VDC at 2 A) Input |
| Power Consumption | 2 VDC (2.5 W) |
| ESD Protection | None |
Environmental
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Storage Temperature | -4 to 140°F / -20 to 60°C |
| Operating Humidity | 20 to 90% (Non-Condensing) |
General
| Material of Construction | Metal |
| Dimensions | 5.2 x 2.1 x 1.1" / 133.0 x 53.0 x 28.0 mm |
| Weight | 7 oz / 198 g |
Packaging Info
| Package Weight | 1.11 lb |
| Box Dimensions (LxWxH) | 7 x 5.6 x 5.1" |
