| ₹ 30750.0 includes GST and import duties. | |
| B2B customers can avail ₹ 4689.38 ITC on this product | |
| 100% Secure Payments | 100% Genuine product | |
| The product is eligible for Free Shipping |
Description
BZBGEAR MV41A-G2 Overview
The 4x1 UHD 4K HDMI Seamless Switcher/Scaler/Multiviewer from BZBGEAR features four HDMI inputs and one HDMI output to facilitate displaying up to four images on a single display. Suitable for residential and commercial applications, the unit supports up to UHD 4K30 resolutions. It can also extract audio for output via its analog port for speakers and audio systems.
Additional Details
- Input and output resolutions up to 4K30
- Smooth transitions with both automatic and manual input selection in single-view or multiview modes
- Special effects and transitions
- Multiview mode offers eight layouts, including Single, PiP, PbP (1/2), Triple (1/2), and Quad (1/2)
- Audio de-embedding to output audio via analog stereo connection
- HD Voice wideband audio
- Independent audio routing allows you to select audio sources separately from video
- Operate via front panel buttons, IR remote, or RS-232 commands
- Compact, space-saving design for flexible integration
- On-screen display (OSD) for multi-view layouts
- Supports up to 10.2 Gb/s video bandwidth
- Fully compliant with HDMI 1.4b and HDCP 1.4 standards
- Advanced EDID management ensures compatibility with connected devices
- Works with LPCM, Dolby Digital (DD), Dolby Digital Plus (DD+), and DTS audio formats
UPC: 850050134978
Items Included
- BZBGEAR 4x1 UHD 4K HDMI Seamless Switcher/Scaler/Multiviewer
- 12 VDC, 2A Power Supply
- Remote Control
- Limited 5-Year Manufacturer Warranty
Additional Resources
BZBGEAR MV41A-G2 Specs
Processing
| Switching Type |
IR Remote, Pushbutton, Software
|
| Processing Resolution |
UHD 4K at 30
|
Input
| Video Inputs |
4x HDMI Female
|
| Input Video Format |
HDMI
UHD 4K up to 30 fps 1080p up to 24/25/30/50/60 fps 1080i up to 50/60 fps 720p up to 50/60 fps 576p at 50 fps 576i / 625 lines at 50 fps 480p at 60 fps 480i / 525 lines at 60 fps |
| Embedded Audio Input |
HDMI
|
Output
| Video Outputs |
1x HDMI (2.1) Female
|
| Output Video Format |
HDMI
UHD 4K up to 30 fps 1080p up to 24/25/30/50/60 fps 1080i up to 50/60 fps 720p up to 50/60 fps 576p at 50 fps 576i / 625 lines at 50 fps 480p at 60 fps 480i / 525 lines at 60 fps |
| Audio Outputs |
1x 1/8" / 3.5 mm TRS Stereo Analog Female
|
| Output Audio Format |
LPCM (Linear Pulse-Code Modulation)
|
| Embedded Audio Output |
HDMI
|
| Multiview Output |
4-Way Multiview via HDMI
|
Connectivity
| Other I/O |
1x USB-C Firmware Input
1x Block 3-Pin RS-232 Input/Output |
| Digital Audio Decoding |
LPCM, Dolby Atmos, Dolby Digital / AC3, Dolby Digital EX, Dolby Digital Plus, Dolby TrueHD, DTS, DTS 96/24, DTS Express, DTS-HD High Resolution, DTS-HD Master Audio
|
| HDCP Support |
Yes: Version 1.4
|
Hardware
| Wireless |
No
|
Power
| Power I/O |
1x Barrel (12 VDC at 2 A) Input
|
| Power Consumption |
Device: 10 W
|
General
| Operating Conditions |
32 to 158?F / 0 to 70?C at 10 to 85% Humidity
|
| Storage Conditions |
14 to 176?F / -10 to 80?C at 5 to 90% Humidity
|
| Certifications |
CE, FCC, REACH, RoHS, UL
|
| Dimensions |
5.8 x 4.1 x 0.85" / 14.7 x 10.4 x 2.16 cm
|
| Weight |
12.1 oz / 342 g
|
Packaging Info
| Package Weight |
1.49 lb
|
| Box Dimensions (LxWxH) |
8 x 7.2 x 1.9"
|
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 30135.0 |
| 3-5 | ₹ 29827.5 |
| 5-10 | ₹ 29212.5 |
| 10+ | ₹ 28597.5 |
Bulk discount will be automatically applied during checkout based on quantity.
