Description
BZBGEAR 4x1 8K UHD HDMI/USB-C 2.1 Switcher Overview
The 4x1 UHD 8K HDMI/USB-C 2.1 Switcher from BZBGEAR features three HDMI 2.1 inputs, one USB-C input, and one HDMI 2.1 output to facilitate HDR video content display. Suitable for residential and commercial applications, the unit's HDR10, HLG, and Dolby Vision compatibility enables you to view your HDR content in rich, full detail. The HDMI supports up to 8K60 and 4K120 resolutions and the USB-C supports up to 8K30 and 4K120 resolutions.
Additional Details
- Three HDMI inputs and one USB-C input, routed to a single HDMI output
- USB-C supports resolutions up to 8K30 (4:2:2, 10-bit) and 4K120 (4:2:2, 10-bit)
- HDMI supports resolutions up to 8K60 (4:2:0, 12-bit), 8K30 (4:4:4, 12-bit), and 4K120 (4:4:4, 12-bit)
- Automatic and manual input switching, controllable via front panel buttons and IR remote
- CEC passthrough control from the display (output) to the source device (input)
- Supports LPCM 7.1 Ch, Dolby TrueHD, Dolby Atmos, DTS-HD Master Audio, and DTS:X audio passthrough formats
- Passes HDR formats, including HDR, HDR10, HDR10+, Dolby Vision, and HLG through
- Advanced HDMI 2.1 features include VRR (Variable Refresh Rate), ALLM (Auto Low-Latency Mode), QMS (Quick Media Switching), QFT (Quick Frame Transport), and SBTM (Source-Based Tone Mapping)
- Customizable advanced EDID settings for flexible compatibility with various displays and sources
- Compliant with DisplayPort 1.4 and HDCP 2.3 standards
UPC: 850050134954
Items Included
- BZBGEAR 4x1 UHD 8K HDMI/USB-C 2.1 Switcher
- IR Remote
- 5V, 1A Power Supply
- Limited 5-Year Manufacturer Warranty
Additional Resources
BZBGEAR 4x1 8K UHD HDMI/USB-C 2.1 Switcher Specs
Processing
| Switching Type |
IR Remote, Pushbutton, Software
|
| Processing Resolution |
8K at 60
|
| Color Processing |
8-Bit 4:4:4 YUV
8-Bit 4:2:2 YUV 8-Bit 4:2:0 YUV 8-Bit 4:4:4 RGB 8-Bit 4:2:2 RGB 8-Bit 4:2:0 RGB 10-Bit 4:4:4 YUV 10-Bit 4:2:2 YUV 10-Bit 4:2:0 YUV 10-Bit 4:4:4 RGB 10-Bit 4:2:2 RGB 10-Bit 4:2:0 RGB 12-Bit 4:4:4 YUV 12-Bit 4:2:2 YUV 12-Bit 4:2:0 YUV 12-Bit 4:4:4 RGB 12-Bit 4:2:2 RGB 12-Bit 4:2:0 RGB |
Input
| Video Inputs |
3x HDMI (2.1) Female
1x USB-C Female |
| Input Video Format |
HDMI (8/10/12-Bit 4:2:0 RGB, YUV)
8K up to 30/60 fps DCI 4K up to 24/60/120 fps UHD 4K up to 24/60/120 fps 1080p up to 60 fps HDMI (8/10/12-Bit 4:4:4 RGB, YUV) DCI 4K up to 24/60/120 fps USB-C (8/10-Bit 4:2:2 RGB, YUV) DCI 4K up to 24/60/120 fps USB-C (8/10-Bit 4:2:2 RGB, YUV) 8K up to 30 fps DCI 4K up to 24/60/120 fps UHD 4K up to 24/60/120 fps 1080p up to 60 fps |
| Embedded Audio Input |
HDMI
|
Output
| Video Outputs |
1x HDMI (2.1) Female
|
| Output Video Format |
HDMI (8/10/12-Bit 4:4:4/4:2:2/4:2:0 RGB, YUV)
8K up to 30/60 fps DCI 4K up to 24/60/120 fps UHD 4K up to 60/120 fps 1080p up to 60 fps |
| Embedded Audio Output |
HDMI
|
| Multiview Output |
4-Way Multiview via HDMI
|
Connectivity
| Other I/O |
1x USB-C Firmware Input
|
| Digital Audio Decoding |
LPCM, Dolby Atmos, Dolby Digital / AC3, Dolby Digital EX, Dolby Digital Plus, Dolby TrueHD, DTS, DTS 96/24, DTS Express, DTS-HD High Resolution, DTS-HD Master Audio
|
| HDCP Support |
Yes: Version 2.3
|
Hardware
| Wireless |
No
|
Power
| Power I/O |
1x Barrel (5 VDC at 1 A) Input
|
| Power Consumption |
Device: 100 to 240 VAC (2.25 W)
|
General
| Operating Conditions |
32 to 104?F / 0 to 40?C at 20 to 90% Humidity
|
| Storage Conditions |
-4 to 140?F / -20 to 60?C at 20 to 90% Humidity
|
| Dimensions |
5.7 x 2.7 x 0.7" / 14.5 x 6.9 x 1.8 cm
|
| Weight |
0.6 lb / 258 g
|
Packaging Info
| Package Weight |
1.045 lb
|
| Box Dimensions (LxWxH) |
8 x 5.2 x 2.9"
|
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
