Description
The CTB9400/3 is a 3-pole 500V/12A female pluggable rising clamp Terminal Block with UL94-V0 flame retardant PA green polarised moulding, tinned phosphor bronze pin/terminal, nickel copper flash brass rising clamp, M3 steel zinc plated captive screw, solid block, 7.5mm pitch. It features anti solder wicking and guided pin alignment. It accepts 0.2 to 2.5mm� (30 to 12AWG) solid and stranded cable.
- >=3kV Dielectric strength
- 6kV Impulse withstand voltage
- 0.5Nm Torque
- 1.4mm Recommended PCB hole size
Applications
Industrial
Product details
| Wire Size AWG Max | 12AWG |
| Wire Connection Method | Screw |
| Rated Current | 12A |
| No. of Positions | 3Ways |
| Conductor Area CSA | 2.5mm� |
| Product Range | CTB9400 Series |
| Pitch Spacing | 7.5mm |
| Wire Size AWG Min | 30AWG |
| Rated Voltage | 500V |
Other details
| Brand | CAMDENBOSS |
| Part Number | CTB9400/3 |
| Quantity | Each |
| Technical Data Sheet EN |  |
