Description
Corsair CX650M Overview
- 1Description
- 280 PLUS Bronze
- 3Low-Noise Operation
- 4Semi-Modular Cabling
- 5Robust DC-DC Conversion
- 6Compact Design
Provide clean, reliable power to your computer with the CX-M Series CX650M 650W 80 PLUS Bronze Semi-Modular Power Supply from Corsair. This compact ATX-sized power supply is designed to provide up to 650W of power, which is enough to handle most single graphic card configurations. The semi-modular cable design helps you to keep a neat, organized layout by letting you use only the cables that you need. The single 120mm fan is designed to maintain optimal performance with minimal noise.
80 PLUS Bronze
The 80 Plus Bronze certification ensures that the CX650M delivers up to 85% efficiency at full load.
Low-Noise Operation
The 120mm rifle bearing fan is designed to produce minimal noise and efficient cooling.
Semi-Modular Cabling
Maintain a clean build by only using the cables you need.
Robust DC-DC Conversion
The CX650M provides clean and consistent power with reliable DC-DC conversion and 221°F rated Japanese primary capacitors.
Compact Design
Measuring just 5.5" long, this power supply fits most ATX compatible cases.
UPC: 840006616528
In the Box
- Corsair CX-M Series CX650M 650W 80 PLUS Bronze Semi-Modular Power Supply
- AC Power Cable
- Modular DC Cable Set
- Cable Ties
- Mounting Screws
- Limited 5-Year Manufacturer Warranty
Table of Contents
- Description
- 80 PLUS Bronze
- Low-Noise Operation
- Semi-Modular Cabling
- Robust DC-DC Conversion
- Compact Design
Corsair CX650M Specs
Connectivity
| Total Connectors | 1 x 24-Pin ATX Motherboard 2 x 4+4-Pin EPS CPU 2 x 6+2-Pin PCIe 2 x 6-Pin SATA / Peripheral |
| Cable Design | Semi-Modular |
| PCIe Connector Distances | 29.5" / 750 mm |
| SATA Connector Distances | 23.6" / 600 mm |
| Peripheral Connector Distances | 29.5" / 750 mm |
| ATX Connector Distance | 23.6" / 600 mm |
| EPS Connector Distances | 25.6" / 650 mm |
Electrical
| Total Wattage | 650 W |
| Number of +12 V Rails | 1 |
| Combined Power for +12 V | 648 W |
| Max Load for +12 V | 54 A |
| Combined Power for +3.3/+5 V | 130 W |
| Max Load for +3.3 V | 20 A |
| Max Load for +5 V | 20 A |
| Max Power for +5 Vsb | 15 W |
| Max Load for +5 Vsb | 3 A |
| Max Power for -12 V | 3.6 W |
| Max Load for -12 V | 0.3 A |
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
General
| Efficiency Rating | 80 PLUS Bronze |
| Active Power Factor Correction | None |
| Efficiency | 82 to 85% |
Cooling
| Fan Size | 120 mm |
| Bearing Type | Rifle |
Physical
| Form Factor | ATX |
| Compliance | ATX 12 V v2.4, EPS 12 V v2.92 |
| Mean Time Between Failures (MTBF) | 100,000 Hours |
| Dimensions | 5.9 x 3.4 x 5.5" / 150 x 86 x 140 mm |
Packaging Info
| Package Weight | 5.065 lb |
| Box Dimensions (LxWxH) | 10.6 x 7.6 x 4" |
