The VARIOFAN family offers temperature-controlled compact axials which adapt their speed according to cooling requirements. A temperature sensor provides the fan with information via an additional control cable and the fan then changes its speed depending on the temperature at the NTC. Being programmed with temperature dependent speed profiles allows adjustment according to the conditions and thereby cooling becomes more flexible and economical.
- Speed Setting via temperature
- Control range Tmin 30 ?C - Tmax 50 ?C
- Higher operating efficiency
- Quieter cooling characteristics
- Supplied with thermistor
Applications
Electronics, Heating and Ventilation, Laminar Flow / Clean Room, Lighting, Power Supplies, RAC, Sorting Equipment
Product details
| Supply Voltage |
12V |
| Current Type |
DC |
| Fan Frame Size |
80mm |
| External Depth |
25mm |
| Flow Rate - Imperial |
26.5cu.ft/min |
| Flow Rate - Metric |
45m?/h |
| Noise Rating |
19dBA |
| Bearing Type |
Sleeve |
| Power Connection Type |
2 Lead Wires |
| Current Rating |
- |
| Product Range |
8400N Series |
| Power Rating |
- |
Other details
| Brand |
EBM-PAPST |
| Part Number |
8412NGMLV |
| Quantity |
Each |
| Technical Data Sheet EN |
 |
| CAD Multiple Formats EN |
|
| Suffix Chart EN |
|
