ENTTEC ELM LED Mapper Entry Editon (4U License)

Roll over image to zoom in

ENTTEC ELM LED Mapper Entry Editon (4U License)


	₹ 23160.0 includes GST and import duties.
	B2B customers can avail ₹ 3531.9 ITC on this product
	100% Secure Payments \| 100% Genuine product
	The product is eligible for Free Shipping

Brand:	ENTTEC
SKU:	6981122523221
MPN:	70581-ETY

Share this product

ENTTEC E.L.M LED Mapper Overview

1Description
2Scalable and Responsive Design
3A Hub for Your Media
4Effects and Audio Reaction
5Natural Design and Interactive Control
6Multi-Protocol Support
73D LED Control
8System and Software Requirements

Program eye-dazzling light shows and control 2D and 3D pixel mapping with style with the ELM LED Mapper Entry Editon from ENTTEC. This version of the powerful and intuitive pixel mapping software is ideal for nightclubs and live touring designs with control for up to 4 universes, providing you with a comprehensive set of tools that lets you seamlessly map LED digital pixel strip or fixture arrays of all shapes and sizes.

Create unique visual effects and set these to music or other sound effects using the integrated generative effects library, or map live video inputs and pre-rendered video content. A built-in effects scheduler facilitates playback of programmed sequences, and you can also control your lighting effects in real time using a number of industry-standard input protocols.

ELM supports Art-Net, sACN, and KiNet protocols and displays video content on LED fixtures of any shape, allowing you to synchronize across multiple DMX nodes and pixel controllers for reliable and pixel-perfect playback. ELM's vector-based mapping makes it powerful and intuitive without requiring you to be a 3D CAD engineer. The software is compatible with Windows 7 operating systems or later versions, with Windows 10 and 11 being the recommended options for greater stability and larger venues.

Scalable and Responsive Design

Combine raster-based media with vector-based scalable and repositionable objects to represent your LED strips, so it even handles the curves beautifully and with just a few mouse clicks.

A Hub for Your Media

Load video files, still images, camera feeds, or live streams into the slots in your library and click on what you want to display. It supports HD video playback and is SPOUT-compatible for live video inputs. It can also act as a Network Device Interface (NDI) receiver. A professional generative video effects library is included to get you started.

Effects and Audio Reaction

Over 100 built-in generative effects that you can personalize as needed. Control pixels using these magic presets or add your own media, generative effects, and live video from input sources such as SPOUT and NewTek's NDI (supports v4.5). Alternatively, just flip a switch and ELM automatically mixes your media in sync with the music playing on your computer.

Natural Design and Interactive Control

Build your show in stages that layer on top of one another simply but powerfully. Use organically shaped objects that you can quickly resize, stretch, deform, or move around on the screen so that your pixel map looks like your pixel strips do in the real world. ELM lets you run a show with live interaction, scheduled playback, or via DMX control from a lighting console.

Multi-Protocol Support

Supports Art-Net, sACN, and KiNet protocols as output. It can be remote controlled via DMX, OSC, or HTTP. It supports an extensive range of LEDs such as RGB, RGBW, RGBA, RGBAW/RGBWA, and White fixtures, including 16-bit protocols, such as ENTTEC 9PDOT.

3D LED Control

Designed to allow existing users to pick it up instantly and begin building it into their current creative workflow. Complex volumetric effects can be easily created using ELM's tested generative media effects, merge modes, and input methods while allowing for precise control of each individual slice of the model, opening a new approach to quickly generate effects.

System and Software Requirements

Minimum:

Windows 7 or later
Dual-core 2 GHz CPU
2 GB RAM- NVIDIA GeForce 600 series or Intel HD Graphics 5500, released after 2013 with OpenGL3.3 support

Recommended:

Windows 10 or 11
Quad core 3.5 GHz CPU
8 GB RAM- NVIDIA GeForce 900 series or NVIDIA 10 series or better
SSD hard drive

In the Box

ENTTEC ELM LED Mapper Entry Editon (4U License)

User Manual

2.1 MB

Table of Contents

Description
Scalable and Responsive Design
A Hub for Your Media
Effects and Audio Reaction
Natural Design and Interactive Control
Multi-Protocol Support
3D LED Control
System and Software Requirements

ENTTEC E.L.M LED Mapper Specs

All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.

Quantity	Price
2	₹ 22696.8
3-5	₹ 22465.2
5-10	₹ 22002.0
10+	₹ 21538.8

Bulk discount will be automatically applied during checkout based on quantity.
