Description
ENTTEC Octo Mk2 Overview
- 1Description
- 2Firmware Updated for Increased Flexibility
- 3Details
- 4Professional Networking
- 5Web Configuration
- 6Power
- 7Ideal for Tight Spaces
- 8Flexible Mounting Options
Take your architectural, commercial, and entertainment projects to the next level using the OCTO Mk2 LED Pixel Controller from ENTTEC. This compact dual-output eDMX to LED pixel data converter is a reliable choice to directly connect to your pixels. A great choice for the ultra-fast deployment of LED strips and pixel dot systems with up to eight universes of Ethernet-DMX to pixel protocol conversion. You can have multiple OCTO Mk2 chained together to easily expand the network. TS35 DIN rail, surface mount options, and network chaining make the OCTO Mk2 a versatile LED pixel control device. It includes an ELM LED mapping software license for your convenience.
Note:
OCTO Mk2 does not provide power to the lighting fixture.
Firmware Updated for Increased Flexibility
- UL certification to ensure the safety and reliability of the OCTO Mk2
- The Overdrive mode allows users to configure the OCTO Mk2 to output more than four universes per port, which may result in a lower maximum FPS
- The Standalone mode allows users to create and edit gradient FX effects with real-time previews seamlessly
- You can configure the OCTO Mk2 to run in Standalone mode upon power-up, with no need for an external DMX source
Details
- Controls up to eight universes of pixels (1024 RGBW / 1360 RGB / 4096 W)
- 4096 channels
- Supports more than 20 pre-listed pixel output protocols
- Test/Reset button allows installers to quickly check if the wiring is correct
- Compatible with third-party software and applications
Professional Networking
- Supports Art-Net, sACN, and KiNet inputs to give flexibility to your projects
- ArtSync ensures that all pixel and DMX outputs are synchronized to avoid image tearing
- The OCTO Mk2 allows either DHCP or Static IP configuration to suit your requirements
Web Configuration
The OCTO Mk2's intuitive web-based configuration gives you access to configure, update, and monitor the temperature using your preferred browser from anywhere on the network. Besides that, grouping functionality is available to reduce the control channel count while still controlling up to eight universes of LED pixels.
Power
Whether you want to control 5V pixel tape or 60V pixel dots, the OCTO Mk2's wide voltage input range will give you the flexibility to power it directly using the same source of your LED pixels.
Ideal for Tight Spaces
Multiple units can be chained together with a maximum cable length of 328' between devices to dramatically cut down the number of cable runs required. Up to 50 units can be linked per chain, though ENTTEC recommends eight devices per chain for optimum visual synchronization.
Flexible Mounting Options
The OCTO Mk2's compact case is capable of being surface mounted in various orientations or fitted to a TS35 DIN rail using its included DIN clip.
In the Box
- ENTTEC OCTO Mk2 LED Pixel Controller
- 2 x WAGO Connector
- DIN Clip and Screws
- 8-Universe ELM Software License
- Limited 3-Year Manufacturer Warranty
Table of Contents
- Description
- Firmware Updated for Increased Flexibility
- Details
- Professional Networking
- Web Configuration
- Power
- Ideal for Tight Spaces
- Flexible Mounting Options
ENTTEC Octo Mk2 Specs
Key Specs
| Inputs/Outputs |
1x RJ45 (10/100 Ethernet) Female Input
1x RJ45 (10/100 Ethernet) Female Output 2x Phoenix 4-Pin (10/100 Ethernet) Output 1x Phoenix 2-Pin (Power) |
| Channels |
4096
|
| Power Source |
AC Adapter
|
| Protocol |
ArtNet, sACN, KiNET, ESP
|
General
| Inputs/Outputs |
1x RJ45 (10/100 Ethernet) Female Input
1x RJ45 (10/100 Ethernet) Female Output 2x Phoenix 4-Pin (10/100 Ethernet) Output 1x Phoenix 2-Pin (Power) |
| Channels |
4096
|
| Dimming |
Optional
|
Power
| Power Source |
AC Adapter
|
| Power Consumption |
5 W
|
| DC Input Power |
5 to 60 VDC
|
Compatibility
| Protocol |
ArtNet, sACN, KiNET, ESP
|
Environmental
| Operating Temperature |
-4 to 122°F / -20 to 50°C
|
| Humidity |
5 to 95% Non-Condensing Operating
|
| Certifications |
UL
|
Physical
| Material of Construction |
Plastic
|
| Dimensions |
4.0 x 2.8 x 1.3" / 100.5 x 72.2 x 34.0 mm
|
| Weight |
0.24 lb / 0.11 kg
|
Packaging Info
| Package Weight |
0.395 lb
|
| Box Dimensions (LxWxH) |
6.5 x 6 x 1.7"
|
