Description
ETC Opto-Splitter Overview
The rackmount ETC Response Opto 16-Port Terminal Splitter features DMX input and throughput ports and provides reliable DMX data distribution. Using DMX and RDM protocols, the splitter is offered as a solution that unlocks the power of your DMX system. It has optically isolated DMX512 ports and supports DMX512, DMX512 (1990), and DMX512-A. It supports ANSI E1.20 RDM and up to 256 total RDM devices. This 19" rackmount version offers front- and rear-facing mounting options.
Items Included
- ETC Response Opto 16-Port Terminal Splitter (Rackmount)
Additional Resources
No additional resources available
ETC Opto-Splitter Specs
Key Specs
| Inputs/Outputs |
16x Terminal 3-Pin (DMX) Output
1x Terminal 3-Pin (DMX) Input 1x Terminal 3-Pin (DMX) Throughput 1x IEC (Power) Input |
| Channels |
512
|
| Power Source |
AC Power
|
| Protocol |
DMX512, RDM
|
General
| Inputs/Outputs |
16x Terminal 3-Pin (DMX) Output
1x Terminal 3-Pin (DMX) Input 1x Terminal 3-Pin (DMX) Throughput 1x IEC (Power) Input |
| Channels |
512
|
| Dimming |
Optional
|
| Cooling System |
No
|
Power
| Power Source |
AC Power
|
| Power Consumption |
35 W
|
| Input Power |
100 to 240 VAC, 50 / 60 Hz
|
Compatibility
| Protocol |
DMX512, RDM
|
Physical
| Operating Conditions |
14 to 149°F / -10 to 65°C at 5 to 95% Humidity
|
| Storage Conditions |
14 to 158°F / -10 to 70°C
|
| Certifications |
cETLus, CE, RoHS, WEEE
|
| Environmental Resistance |
No
|
| Material of Construction |
Aluminum
|
| Dimensions |
19.0 x 4.8 x 1.7" / 48.3 x 12.2 x 4.3 cm (Including Mounting Bracket)
|
| Weight |
2.5 lb / 1.1 kg
|
