Gigabyte Z890 AERO G LGA 1851 ATX Motherboard (Snow White)

AORUS AI SNATCH

Unleash optimal performance with one-click activation. With just a single click, unleash the full potential of DDR5 memory, instantly boosting performance for gaming and creative content. Get enhanced computing power, fast AI performance, EZ to Peak, safe overclocking, and less power usage.

Wi-Fi 7

Wi-Fi 7 introduces support for expansive 320/160 MHz channels, dramatically increasing bandwidth for fast data transfer speeds. Leveraging 4K-QAM technology, Wi-Fi 7 elevates data throughput, enabling fast file transfers and buffer-free streaming.

Wi-Fi 7's MLO (Multi-Link Operation) technology allows strategic bandwidth allocation - dedicating 2.4 GHz for streaming and 5/6 GHz for gaming, resulting in an interruption-free network experience.

With low latency, Wi-Fi 7 minimizes delays, making it the ideal choice for time-sensitive applications, such as video conferencing and competitive online gaming.

Dual 2.5GbE LAN

Supercharge your online gaming with dual 2.5GbE RJ45 LAN jacks. With fast speeds, minimal lag, and optimal performance, you'll be able to elevate your gaming rig for online competition.

EZ-Latch Designs

PCIe EZ-Latch Plus

Easy ejection with a single slick for graphics cards

M.2 EZ-Latch Click

Tool-less installation for M.2 heat sink

M.2 EZ-Latch Plus

Tool-less installation for M.2 SSDs

Additional Key Features

Supports Intel Core Ultra processors (Series 2)

Digital twin 16+1+2 phases VRM solution

VisionLINK for Thunderbolt - one USB-C port for video, data transfer, and charging

Gigabyte Z890 AERO G Specs

Chipset	Intel Z890
CPU Socket	LGA 1851
Memory Slots	4x 288-Pin
Memory Support	DDR5 5600, 5800, 6000, 6200, 6400, 6600, 6800, 7000, 7200, 7400, 7600, 7800, 7900, 7950, 8000, 8200, 8266, 8400, 8600, 8800 MT/s
Storage Slots	1x M.2 (M Key) 2280, 22110, 2580, 25110 (PCIe 5.0 x4, PCIe 5.0 x2) 1x M.2 (M Key) 2280, 22110, 2580, 25110 (PCIe 4.0 x4, PCIe 4.0 x2) 1x M.2 (M Key) 2280, 22110 (PCIe 4.0 x4, PCIe 4.0 x2) 1x M.2 (M Key) 2280 (PCIe 4.0 x4, PCIe 4.0 x2) 1x M.2 (M Key) 2280 (PCIe 4.0 x4, PCIe 4.0 x2, SATA (Unspecified))
Expansion Slots	1x PCIe 5.0 x16 1x PCIe 5.0 x16 (x8 mode) 1x PCIe 4.0 x16 (x4 mode)
Wi-Fi	Wi-Fi 7 (802.11be); Tri-Band (2.4, 5, & 6 GHz) with MU-MIMO Support
Form Factor	ATX

Chipset	Intel Z890
CPU Socket	LGA 1851

USB	2x USB-A (USB 3.1/3.2 Gen 2) 4x USB-A (USB 3.0 / 3.1/3.2 Gen 1) 2x USB-A (USB 2.0)
Thunderbolt	1x Thunderbolt 4
Display	1x HDMI
Audio	2x 1/8" / 3.5 mm 1x S/PDIF
Ethernet / Controller	2x Intel 226 2.5Gigabit
Wi-Fi Antenna	2x Connector

Memory Slots	4x 288-Pin
Memory Support	DDR5 5600, 5800, 6000, 6200, 6400, 6600, 6800, 7000, 7200, 7400, 7600, 7800, 7900, 7950, 8000, 8200, 8266, 8400, 8600, 8800 MT/s
Maximum Capacity	256 GB
Channel Architecture	Dual Channel
ECC Support	Non-ECC, ECC Unbuffered

SATA	4x SATA III
Storage Slots	1x M.2 (M Key) 2280, 22110, 2580, 25110 (PCIe 5.0 x4, PCIe 5.0 x2) 1x M.2 (M Key) 2280, 22110, 2580, 25110 (PCIe 4.0 x4, PCIe 4.0 x2) 1x M.2 (M Key) 2280, 22110 (PCIe 4.0 x4, PCIe 4.0 x2) 1x M.2 (M Key) 2280 (PCIe 4.0 x4, PCIe 4.0 x2) 1x M.2 (M Key) 2280 (PCIe 4.0 x4, PCIe 4.0 x2, SATA (Unspecified))
Optane Memory Support	No
RAID Support	RAID 0, 1, 5, 10

Expansion Slots	1x PCIe 5.0 x16 1x PCIe 5.0 x16 (x8 mode) 1x PCIe 4.0 x16 (x4 mode)
USB	1x USB 3.2 Gen 2x2 Header (Supports 1 USB-C Port) 1x USB 3.0 / 3.1/3.2 Gen 1 Header (Supports 2 USB-A Port) 2x USB 2.0 Header (Supports 4 USB-A Port)
Power Connectors	1x 24-Pin Mainboard
Audio	1x S/PDIF

ROM

256 Mb

Front Panel I/O

USB 3.0 / 3.1/3.2 Gen 1

Audio Codec	Realtek (7.1-Channel)
DAC	No

Wi-Fi	Wi-Fi 7 (802.11be); Tri-Band (2.4, 5, & 6 GHz) with MU-MIMO Support
Bluetooth	5.4

OS Compatibility

Windows

Form Factor	ATX
Dimensions	12.0 x 9.6" / 305 x 244 mm

Package Weight	5.12 lb
Box Dimensions (LxWxH)	13.6 x 10.8 x 3.3"
