| ₹ 9413.85 includes GST and import duties. | |
| B2B customers can avail ₹ 1435.61 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
The MWDM2L-9PSB from Glenair is a Micro-D MWDM series solder cup metal shell connector with 9 contacts. Suitable for use with #26AWG wire.
- Aluminium alloy shell with nickel plating
- Liquid crystal polymer (LCP)/ polyphenylene sulphide(PPS) insulator
- Beryllium copper pin contacts with gold over nickel plating
- Blue colour fluorosilicone rubber interfacial seal
- Current rating is 3A, DWV is 600VAC sea level
- Minimum insulation resistance is 5000Mohm, maximum contact resistance is 8mohm
- Operating temperature range from -55°C to +150°C
- Through hole mounting hardware
Industrial
Other details
| Brand | GLENAIR |
| Part Number | MWDM2L-9PSB |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 9225.57 |
| 3-5 | ₹ 9131.43 |
| 5-10 | ₹ 8943.16 |
| 10+ | ₹ 8754.88 |
Bulk discount will be automatically applied during checkout based on quantity.
