- Designed to house P.C. boards or for equipment interfacing
- Sized for standard Eurocards
- P.C. boards mount horizontally by sliding into internal slots extruded into the enclosure body
- Easy to machine - one piece - front & back plastic end panels
- Rugged body constructed from extruded aluminum with a minimum thickness of .06" (1.5 mm)
- Extruded aluminium body with a slide removable "belly" plate
- Two easy to machine, black solid ABS plastic end panels with integral bezel
- Extruded aluminum body
- Self adhesive clear rubber feet
Footnotes
Product details
| External Depth - Imperial |
8.66" |
| Body Colour |
Black |
| External Width - Metric |
103mm |
| Enclosure Type |
Instrument |
| NEMA Rating |
- |
| External Height - Metric |
53mm |
| External Height - Imperial |
2.09" |
| External Width - Imperial |
4.06" |
| Product Range |
1455 Series |
| IP Rating |
- |
| External Depth - Metric |
220mm |
| Enclosure Material |
Aluminium |
Other details
| Brand |
HAMMOND |
| Part Number |
1455N2202BK |
| Quantity |
Each |
| Technical Data Sheet EN |
 |
| Drawing EN |
|
