Description
The white 50131001 95% BC Braid Shield + 18/2 Stranded Siamese CL2 Cable from Honeywell can be used with alarms, intercoms, speakers, and other low-voltage circuits that are power limited. This cable comes packaged on a reel and is 1000.0' (304.8m) long.
UPC: 619172049276
In the Box
Honeywell 50131001 95% BC Braid Shield + 18/2 Stranded Siamese CL2 Cable (White)
- Limited 36-Month Warranty
| Construction | |
|---|---|
| Conductor | 2 to 18 AWG 19/.0092 stranded bare copper |
| Insulation | 18 AWG 2/C |
| Type | Polypropylene |
| Thickness | 0.006" (0.152 mm) nominal |
| Diameter | 0.058" (1.473 mm) nominal |
| Lay Length | 2.25" (57.15 mm) nominal |
| Stranding | 0.005" (0.127 mm) nominal bare copper |
| Coverage | 95% nominal |
| Jacket | 18 AWG 2/C |
| Type | PVC |
| Thickness | 0.020" (0.508 mm) nominal |
| Diameter | 0.156" (3.962 mm) nominal |
| Overall Diameter | 0.420 x 0.245" (10.668 x 6.223 mm) nominal |
| General | |
|---|---|
| Voltage Rating | 300 V |
| Temperature Rating | -4 to 167�F (-20 to 75�C) |
| Capacitance | 17 pf/ft nominal |
| Impedance | 75 ? nominal |
| Resistance | Conductor: 10.9 ? /M' at 68�F (20�C) Shield: 2.6 ?/M' at 68�F (20�C) |
| Attenuation | 0.2 at 1 MHz, 5.9 at 400 MHz, 10.8 at 1,000 MHz |
| Rating | Flame: UL 1685 Vertical Tray |
| Packaging Info | |
|---|---|
| Package Weight | 48.55 lb |
| Box Dimensions (LxWxH) | 14.5 x 12.992 x 9.685" |
