Description
Honeywell 5003 Overview
The black Genesis Coaxial CATV Cable from Honeywell comes in a reel of 1000' (304.8m) has a AWG #18 copper clad steel conductor. This cable assures good performance for CATV and other applications. It has a dual aluminum foil shield which protects signal transmission from low and high frequency interference. The dual shield is suitable for broadband applications.
General
Countdown or Sequential Footage Markings
Room/Zone Markings on Legend
Sweep tested to 3 GHz
Niitrogen-injected foam polyethylene dielectric
PVC jacket
CATV, CL2 UL rated
Dual Shield
100% aluminum foil shield
45 to 80% aluminum braid shield or 100% tinned copper braid shield
Protects signal transmission from low and high frequency interference
Suitable for broadband applications
UPC: 619172018920
In the Box
- Honeywell Genesis Coaxial CATV Cable (Black, 500' Reel)
- Limited 1-Year Manufacturer Warranty
Honeywell 5003 Specs
Electrical Specifications
| Voltage Rating |
300 V
|
| Capacitance |
Nominal Capacitance: 16.5 pF/ft
|
| Impedance |
Nominal Impedance: 75 ?
|
| Velocity |
Nominal Velocity: 81%
|
| Conductor |
30 ? /1000.0' (304.8 m)
|
Physical Specifications
| Diameter |
Dielectric Diameter: Nominal 0.180" (0.457 cm)
|
| Jacket |
Jacket Diameter: 0.270" (0.685 cm)
|
| Minimum Bend Radius |
3.0" (7.6 cm)
|
| Temperature Rating |
-4 to 167ºF (-20 to 75ºC)
|
| Cable Length |
1000.0' (304.8 m)
|
| Weight |
27.0 lb (12.2 kg)
|
Packaging Info
| Package Weight |
15.35 lb
|
| Box Dimensions (LxWxH) |
9.4 x 9 x 8.8"
|
