Description
Honeywell 5003 Overview
- 1Description
- 2Conductor Material
- 3Shielding
- 4Additional Features
The 1000' long gray Genesis Series 18 AWG RG6/U DUAL-Shielded Broadband Coaxial Cable from Honeywell comes packaged in a pull box. It is a broadband and digital coaxial cable, tested for high standards to assure good performance in high-end home theater installations, incorporating HDTV and digital video. The cable has a foil shielding that protects signal transmission from EMI and RFI interference and blocks lower frequency interference.
Conductor Material
CCS (Copper Clad Steel)
High durability and strength
Common for broadband applications, including CATV / MATV and HDTV
Shielding
Dual shield
100% aluminum foil shield
45 to 80% aluminum braid shield or 100% tinned copper braid shield
Protects signal transmission from low- and high-frequency interference
Suitable for broadband applications
Additional Features
Countdown or sequential footage markings
Camera and room / zone markings on legend
Color-coded box with labeling system
Sunlight resistant
UL Rating: CATV; CL2
Flame Ratings: UL 1685 Vertical Tray
In the Box
- Honeywell Genesis Series 18 AWG RG6/U DUAL-Shielded Broadband Coaxial Cable (Gray, 1000' Pull Box)
Table of Contents
- Description
- Conductor Material
- Shielding
- Additional Features
Honeywell 5003 Specs
| Gauge | 18 AWG |
| Conductor | Copper-clad steel center 30 ?/1,000' |
| Insulation | Nitrogen-injected foam polyethylene dielectric |
| Shield | 100% coverage aluminum foil 60% aluminum braid |
| Stranding | Nominal: 0.005" (0.127 mm) |
| Jacket | PVC |
| Style | RG6/U |
| Minimum Bend Radius | 3.0" (76.2 mm) |
| Frequency | Sweep Frequency: 3 GHz |
| Nominal Impedance | 75 ? |
| Nominal Capacitance | 16.5 pF/ft |
| Nominal Velocity of Propagation | 81% |
| Resistance | 10.9 ?/m at 20°C |
| Attenuation | Minimum SRL: 20 dB 0.7 dB/100' at 5 MHz 1.5 dB/100' at 55 MHz 2.8 dB/100' at 211 MHz 3.9 dB/100' at 400 MHz 4.4 dB/100' at 500 MHz 4.9 dB/100' at 600 MHz 5.5 dB/100' at 750 MHz 6.5 dB/100' at 1,000 MHz Minimum SRL: 15 dB 8.1 dB/100' at 1,500 MHz 8.9 dB/100' at 1,800 MHz 9.9 dB/100' at 2,200 MHz 10.3 dB/100' at 2,400 MHz 11.7 dB/100' at 3,000 MHz |
| Pulling Tension | Maximum: 19.0 lb (8.6 kg) Recommended: 14.25 lb (6.46 kg) |
| Temperature Rating | -4 to 167°F (-20 to 75°C) |
| Voltage Rating | 300 V |
| Diameter | Dielectric: 0.18" (4.57 mm) Nominal Outer Diameter: 0.275" (6.985 mm) |
| Length | 1000.0' (304.8 m) |
| Weight | 30 lb (14 kg) |
